SY89537LMH TR Overview
As a clock IC, PLLs is packaged using the Tape & Reel (TR) method. This clock generator is embedded in the 44-VFQFN Exposed Pad, 44-MLF? package. A clock generator's input is called CMOS, HSTL, LVDS, LVPECL, LVTTL, SSTL, Crystal and it is designed as the input for this clock generator. There are 1 circuits implemented in order to achieve full performance from this electronic part. Providing a maximum frequency of 756MHz, this clock-based RF synthesizer is suitable for a variety of applications. Because of the Surface Mount, clock PLL can be easily mounted on the panel. Clock generator ic works with 2.375V~3.6V. The temperature should be set at -40°C~85°C to ensure reliable performance. I would like to present to you a frequency synthesizer that is compatible with LVDS, LVPECL logic levels. As far as electrical parts go, this component can be classified as a Clock/Frequency Synthesizer component. Related electrical parts can be found for the base part number SY89537. An electronic part belonging to the Precision Edge? series is being used here.
SY89537LMH TR Features
Available in the 44-VFQFN Exposed Pad, 44-MLF?
SY89537LMH TR Applications
There are a lot of Microchip Technology SY89537LMH TR Clock Generators applications.
- 1 Gigabit Ethernet
- Frequency Modulation (FM) stereo decoders
- Local oscillators (LOs)
- Wi-Fi routers
- FPGA and processor clocks
- Time to digital converters
- Satellite navigation communication
- DVD add-on cards for multimedia PCs
- Deep space exploration
- Clock recovery
