Name: PIC32MX695F512L-80I/PF
Brand: Microchip Technology
SKU: PIC32MX695F512L-80I/PF
Price: 14.26000 USD
Availability: InStock

new

PIC32MX695F512L-80I/PF

Manufacturer part number:PIC32MX695F512L-80I/PF

Manufacturer:Microchip Technology

Description:512KB 512K x 8 FLASH MIPS32® M4K™ 32-Bit Microcontroller PIC® 32MX Series PIC32MX695F512L 100 Pin 80MHz 3.3V 100-TQFP

Case Package:SOT-23

Datasheet:PIC32MX695F512L-80I/PF Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	100-TQFP
Number of Pins	100
Supplier Device Package	100-TQFP (14x14)
Mounting Style	SMD/SMT
Interfaces	Ethernet/I2C/SPI/UAR
Data Converters	A/D 16x10b
MSL	MSL 3 - 168 hours
Number of I/Os	83 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	CAN, I2C, SPI, UART, USB
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	MIPS32
RoHS	Details
Product Status	Active
Mfr	Microchip Technology
Base Product Number	PIC32MX695
Package	Tray
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	PIC® 32MX
Published	2009
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	100
Termination	SMD/SMT
Terminal Finish	Matte Tin (Sn) - annealed
Terminal Position	QUAD
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Frequency	80MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC32MX695F512L
Pin Count	100
Supply Voltage-Min (Vsup)	2.3V
Interface	CAN, Ethernet, I2C, SPI, UART, USART, USB
Memory Size	512kB
Oscillator Type	Internal
Number of I/O	85
Speed	80MHz
RAM Size	128K x 8
Voltage - Supply (Vcc/Vdd)	2.3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	32
Core Processor	MIPS32® M4K™
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	512KB 512K x 8
Connectivity	Ethernet, I2C, SPI, UART/USART, USB OTG
Supply Current-Max	98mA
Bit Size	32
Data Converter	A/D 16x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	32b
PWM Channels	YES
Number of Timers/Counters	5 Timer
Product Type	32-bit Microcontrollers - MCU
Density	4 Mb
Core Architecture	PIC
EEPROM Size	--
CPU Family	PIC
Number of A/D Converters	1
Number of Programmable I/O	83
Number of UART Channels	6
Number of ADC Channels	16
Number of I2C Channels	5
Number of SPI Channels	4
Product	MCU
Product Category	32-bit Microcontrollers - MCU
Device Core	PIC32
Height	1.05mm
Length	12mm
Width	12mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC32MX695F512L-80I/PF Product Details

PIC32MX695F512L-80I/PF Description

The PIC32MX695F512L-80I/PF is a high performance 32-bit microcontroller from the PIC32MX family that features a MIPS M4K core and a potent PIC®(RISC) architecture. With standardized features including 512kB of addressable program memory, 12kB of auxiliary flash, 131072bytes of data memory, two comparators, and a 16-channel 10-bit analog-to-digital (A/D) converter, this product offers all the benefits of the well-known high-performance x32 design. With a wide operating voltage range of 2.3 to 3.6V, this device operates at a maximum frequency of 80MHz.
