Name: PIC24FV16KA301T-I/SO
Brand: Microchip Technology
SKU: PIC24FV16KA301T-I/SO
Availability: InStock

new-10%

PIC24FV16KA301T-I/SO

Manufacturer part number:PIC24FV16KA301T-I/SO

Manufacturer:Microchip Technology

Description:16KB 5.5K x 24 FLASH PIC 16-Bit Microcontroller PIC® XLP™ 24F Series PIC24FV16KA301 20 Pin 32MHz 3.3V 20-SOIC (0.295, 7.50mm Width)

Case Package:SOT-23

Datasheet:PIC24FV16KA301T-I/SO Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-SOIC (0.295, 7.50mm Width)
Number of Pins	20
Supplier Device Package	20-SOIC
Data Converters	A/D 12x12b
Package	Tape & Reel (TR)
Base Product Number	PIC24FV16KA301
Mfr	Microchip Technology
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	PIC® XLP™ 24F
Published	2011
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	20
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn)
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	1.27mm
Frequency	32MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC24FV16KA301
Pin Count	20
Supply Voltage-Min (Vsup)	2V
Interface	I2C, IrDA, LIN, SPI, UART, USART
Memory Size	16kB
Oscillator Type	Internal
Number of I/O	17
Speed	32MHz
RAM Size	2K x 8
Voltage - Supply (Vcc/Vdd)	2V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	16KB 5.5K x 24
Connectivity	I2C, IrDA, LINbus, SPI, UART/USART
Bit Size	16
Data Converter	A/D 12x12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	5
EEPROM Size	512 x 8
On Chip Program ROM Width	24
Boundary Scan	NO
Low Power Mode	YES
Screening Level	TS-16949
Format	FIXED-POINT
Integrated Cache	NO
Number of External Interrupts	3
On Chip Data RAM Width	16
Time-Min	SECONDS
Length	12.8mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC24FV16KA301T-I/SO Product Details

PIC24FV16KA301T-I/SO Overview

This Microcontroller comes in a 20-SOIC (0.295, 7.50mm Width) package. This Microcontroller has 17 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 16-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~85°C TA Operating Temperature. Microcontroller runs in PIC® XLP™ 24F Series. The size of the program memory of Microcontroller is 16KB 5.5K x 24. MCU is powered by PIC Core Processor. The device belongs to MICROCONTROLLER uPs/uCs/Peripheral ICs Type. The MCU has a number of 20 terminals. Microcontroller comes with 16 bit size. The component always operates in 3.3V supply voltage. MCU chip has NO DMA channels. The part owns 16kB memory size. You can find alternatives through the base part number PIC24FV16KA301. MCU's frequency is 32MHz. The device works in YES PWM channels. The pin number of the component remains 20. It has 5 timers/counters. It counts 20 pins. 3 external interrupts are included in the eletrical part.
