Name: PIC18LF43K22-E/ML
Brand: Microchip Technology
SKU: PIC18LF43K22-E/ML
Availability: InStock

new-10%

PIC18LF43K22-E/ML

Manufacturer part number:PIC18LF43K22-E/ML

Manufacturer:Microchip Technology

Description:8KB 4K x 16 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 18K Series PIC18LF43K22 44 Pin 48MHz 3V 44-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC18LF43K22-E/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-VQFN Exposed Pad
Number of Pins	44
Supplier Device Package	44-QFN (8x8)
Interfaces	I2C/SPI/USART
RoHS	Compliant
Package	Tube
Base Product Number	PIC18LF43
Mfr	Microchip Technology
Data Converters	A/D 30x10b
Product Status	Active
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Series	PIC® XLP™ 18K
Published	2010
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	44
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	125 °C
Min Operating Temperature	-40 °C
Max Power Dissipation	1W
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.65mm
Frequency	48MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC18LF43K22
Pin Count	44
Supply Voltage-Max (Vsup)	3.6V
Interface	I2C, SPI, UART, USART
Max Supply Voltage	3.6 V
Min Supply Voltage	1.8 V
Memory Size	8kB
Oscillator Type	Internal
Number of I/O	35
Speed	48MHz
RAM Size	512 x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	8
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	8KB 4K x 16
Connectivity	I2C, SPI, UART/USART
Bit Size	8
Data Converter	A/D 30x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
Number of Timers/Counters	7
ROM (words)	4096
Core Architecture	PIC
EEPROM Size	256 x 8
CPU Family	PIC
Max Frequency	16 MHz
Number of A/D Converters	2
Number of Programmable I/O	36
Number of UART Channels	2
Number of ADC Channels	30
Number of I2C Channels	2
Number of SPI Channels	2
Device Core	PIC
Height	950μm
Length	8mm
Width	8mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC18LF43K22-E/ML Product Details

PIC18LF43K22-E/ML Overview

It comes in a 44-VQFN Exposed Pad package. It has a number of 35I/Os. The Mounting Type of the device is Surface Mount. It is based on the 8-Bit. The It?ˉs Program Memory Type is FLASH. The device runs in -40??C~125??C TA Operating Temperature. It runs in PIC? XLP? 18K Series.

PIC18LF43K22-E/ML Features

PIC? XLP? 18K series
Base part number of PIC18LF43K22
44 Terminals
Based on the 8-Bit
Comes with 44 Pins

PIC18LF43K22-E/ML Applications

There are a lot of Microchip Technology PIC18LF43K22-E/ML Microcontroller applications. PIC18LF43K22-E/ML MCU is usually applied for Measurement and control field, Consumer electronics products, Network communication, mobile communication, Office automation equipment and computer peripherals, Industrial control Instrumentation and process control, Agriculture, transportation, Navigation control, Network application, Metering & measurement, Day to day life, Safety, Medical instruments and Automobile industry.
