Name: PIC18LF25J10-I/ML
Brand: Microchip Technology
SKU: PIC18LF25J10-I/ML
Availability: InStock

new-10%

PIC18LF25J10-I/ML

Manufacturer part number:PIC18LF25J10-I/ML

Manufacturer:Microchip Technology

Description:32KB 16K x 16 FLASH PIC 8-Bit Microcontroller PIC® 18J Series PIC18LF25J10 28 Pin 40MHz 2.5V 28-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC18LF25J10-I/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	28-VQFN Exposed Pad
Number of Pins	28
Supplier Device Package	28-QFN (6x6)
Interfaces	I2C/SPI/USART
Package	Tube
Base Product Number	PIC18LF25
Mfr	Microchip Technology
Data Converters	A/D 10x10b
Product Status	Active
Operating Temperature	-40°C~85°C TA
Packaging	Tube
Series	PIC® 18J
Published	2006
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
Terminal Finish	Matte Tin (Sn)
Additional Feature	ALSO OPERATES AT 2V MINIMUM SUPPLY AT 4 MHZ
Max Power Dissipation	1W
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	2.5V
Terminal Pitch	0.65mm
Frequency	40MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC18LF25J10
Pin Count	28
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	2.5V
Supply Voltage-Min (Vsup)	2V
Interface	I2C, SPI, UART, USART
Memory Size	32kB
Oscillator Type	Internal
Number of I/O	21
Speed	40MHz
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	2V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	32KB 16K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	22mA
Bit Size	8
Data Converter	A/D 10x10b
Watchdog Timer	Yes
Access Time	40 μs
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	3
EEPROM Size	-
On Chip Program ROM Width	16
Device Core	PIC
Length	6mm
Height Seated (Max)	1mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC18LF25J10-I/ML Product Details

PIC18LF25J10-I/ML Overview

This Microcontroller comes in a 28-VQFN Exposed Pad package. This Microcontroller has 21 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 8-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~85°C TA Operating Temperature. Microcontroller runs in PIC® 18J Series. The size of the program memory of Microcontroller is 32KB 16K x 16. MCU is powered by PIC Core Processor. The device belongs to MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs Type. The MCU has a number of 28 terminals. Microcontroller comes with 8 bit size. The component always operates in 2.5V supply voltage. MCU chip has NO DMA channels. The part owns 32kB memory size. You can find alternatives through the base part number PIC18LF25J10. MCU's frequency is 40MHz. The device works in YES PWM channels. The pin number of the component remains 28. It has 3 timers/counters. It counts 28 pins. To name a few, there are additional features like ALSO OPERATES AT 2V MINIMUM SUPPLY AT 4 MHZ.
