Name: ATSAMD21E16C-UUT
Brand: Microchip Technology
SKU: ATSAMD21E16C-UUT
Availability: InStock

new-10%

ATSAMD21E16C-UUT

Manufacturer part number:ATSAMD21E16C-UUT

Manufacturer:Microchip Technology

Description:64KB 64K x 8 FLASH ARM® Cortex®-M0+ 32-Bit Microcontroller SAM D21E Series ATSAMD21E16 48(MHz) 3.3V 35-XFBGA, WLCSP

Case Package:SOT-23

Datasheet:ATSAMD21E16C-UUT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Mounting Type	Surface Mount
Package / Case	35-XFBGA, WLCSP
Surface Mount	YES
Supplier Device Package	35-WLCSP (2.82x2.53)
Number of Terminals	35
Data Converters	A/D 10x12b, D/A 1x10b
Instruction Set Architecture	RISC
Clock Freq	48(MHz)
DAC Resolution	10
Operating Temperature Classification	Industrial
Package Type	WLCSP
Number of Timers - General Purpose	6
Operating Temp Range	-40C to 85C
# I/Os (Max)	26
Total Internal Ram Size	8KB(kB)
Device Core Size	32(b)
Operating Supply Voltage (Max)	3.63(V)
Operating Supply Voltage (Typ)	3.3(V)
Rad Hardened	No
Operating Supply Voltage (Min)	1.62(V)
Programmable	Yes
Mounting	Surface Mount
Package	Tape & Reel (TR);Cut Tape (CT);
Base Product Number	ATSAMD21
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Number of I/O Lines	26
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	SAM D21E
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	35
HTS Code	8542.31.00.01
Terminal Position	BOTTOM
Terminal Form	BALL
Supply Voltage	3.3V
Terminal Pitch	0.4mm
Reach Compliance Code	compliant
Frequency	48(MHz)
Base Part Number	ATSAMD21E16
Pin Count	35
JESD-30 Code	R-PBGA-B35
Operating Temperature (Max)	85C
Operating Temperature (Min)	-40C
Supply Voltage-Max (Vsup)	3.63V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	1.62V
Oscillator Type	Internal
Number of I/O	26
Speed	48MHz
RAM Size	8K x 8
Voltage - Supply (Vcc/Vdd)	1.62V~3.63V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M0+
Peripherals	Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency	32MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	64KB 64K x 8
Connectivity	I2C, LINbus, SPI, UART/USART, USB
Bit Size	32
Data Converter	A/D 10x12b; D/A 1x10b
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
DAC Channels	YES
Seated Height-Max	0.483 mm
EEPROM Size	--
On Chip Program ROM Width	8
Screening Level	TS 16949
ROM Programmability	FLASH
Device Core	ARM CORTEX M0+
Length	2.821mm
Height Seated (Max)	0.483mm
Width	2.529mm

ATSAMD21E16C-UUT Product Details

ATSAMD21E16C-UUT Overview

The package is in 35-XFBGA, WLCSP format. The MCU has 26 I/O ports. There is a mounting type Surface Mount associated with this Microcontroller. This Microcontroller is based on the 32-Bit core. There is a memory type of FLASH in its program memory. The temperature range that this Microcontroller operates at is -40°C~85°C TA. The electrical component that you are looking at belongs to the SAM D21E series of components. Microcontroller has abundant program memory size of 64KB 64K x 8. The ARM® Cortex®-M0+ Core Processor powers the device and is one of its key features. This Microcontroller belongs to the MICROCONTROLLER, RISC uPs/uCs/peripheral ICs type. During the manufacture of the IC chip, there is a number 35 of terminations. A 32-bit operation is performed by this part. There is an output of 3.3V volts from the Microcontroller chip. A total of YES DMA channels are available on MCU chip. ATSAMD21E16 serves as a base part number to find alternatives. It exhibits good efficiency when it operates at a frequency of 48(MHz) and it is able to operate at a high frequency. It is possible for the device to work with the motor using the PWM channel YES. It consists of 35 pins. In terms of frequency, it operates at a 32MHz clock rate.
