Name: PIC17C42A-33/L
Brand: Microchip Technology
SKU: PIC17C42A-33/L
Availability: InStock

new-10%

PIC17C42A-33/L

Manufacturer part number:PIC17C42A-33/L

Manufacturer:Microchip Technology

Description:4KB 2K x 16 OTP PIC 8-Bit Microcontroller PIC® 17C Series PIC17C42A 44 Pin 33MHz 5V 44-LCC (J-Lead)

Case Package:SOT-23

Datasheet:PIC17C42A-33/L Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	18 Weeks
Mounting Type	Surface Mount
Package / Case	44-LCC (J-Lead)
Surface Mount	YES
Number of Pins	44
Supplier Device Package	44-PLCC (16.59x16.59)
Interfaces	SCI/USART
Package	Tube
Base Product Number	PIC17C42
Mfr	Microchip Technology
Data Converters	-
Product Status	Active
Number of I/Os	33
RoHS	Compliant
Operating Temperature	0°C~70°C TA
Packaging	Tube
Series	PIC® 17C
Published	1996
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	44
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	70 °C
Min Operating Temperature	0 °C
Max Power Dissipation	1W
Terminal Position	QUAD
Terminal Form	J BEND
Peak Reflow Temperature (Cel)	245
Supply Voltage	5V
Terminal Pitch	1.27mm
Frequency	33MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC17C42A
Pin Count	44
Operating Supply Voltage	5V
Supply Voltage-Max (Vsup)	6V
Power Supplies	5V
Interface	SCI, UART, USART
Max Supply Voltage	6 V
Min Supply Voltage	4.5 V
Memory Size	4kB
Oscillator Type	External
Number of I/O	33
Speed	33MHz
RAM Size	232 x 8
Memory Type	OTP
Voltage - Supply (Vcc/Vdd)	4.5V~6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	POR, PWM, WDT
Program Memory Type	OTP
Core Size	8-Bit
Program Memory Size	4KB 2K x 16
Connectivity	UART/USART
Supply Current-Max	50mA
Bit Size	8
Watchdog Timer	Yes
Access Time	33 μs
Has ADC	NO
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Number of Timers/Counters	4
Address Bus Width	16
Core Architecture	PIC
EEPROM Size	-
On Chip Program ROM Width	16
CPU Family	PIC
Max Frequency	33 MHz
Number of Programmable I/O	33
Device Core	PIC
Length	16.5862mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

PIC17C42A-33/L Product Details

PIC17C42A-33/L Overview

It comes in a 44-LCC (J-Lead) package. It has a number of 33I/Os. The Mounting Type of the device is Surface Mount. It is based on the 8-Bit. The It?ˉs Program Memory Type is OTP. The device runs in 0??C~70??C TA Operating Temperature. It runs in PIC? 17C Series.

PIC17C42A-33/L Features

PIC? 17C series
Base part number of PIC17C42A
44 Terminals
Based on the 8-Bit
Comes with 44 Pins

PIC17C42A-33/L Applications

There are a lot of Microchip Technology PIC17C42A-33/L Microcontroller applications. PIC17C42A-33/L MCU is usually applied for Measurement and control field, Consumer electronics products, Network communication, mobile communication, Office automation equipment and computer peripherals, Industrial control Instrumentation and process control, Agriculture, transportation, Navigation control, Network application, Metering & measurement, Day to day life, Safety, Medical instruments and Automobile industry.
