Name: PIC16LF1704-E/SL
Brand: Microchip Technology
SKU: PIC16LF1704-E/SL
Price: 1.20000 USD
Availability: InStock

new-10%

PIC16LF1704-E/SL

Manufacturer part number:PIC16LF1704-E/SL

Manufacturer:Microchip Technology

Description:7KB 4K x 14 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 16F Series PIC16LF1704 14 Pin 32MHz 3.3V 14-SOIC (0.154, 3.90mm Width)

Case Package:SOT-23

Datasheet:PIC16LF1704-E/SL Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mounting Type	Surface Mount
Package / Case	14-SOIC (0.154, 3.90mm Width)
Surface Mount	YES
Number of Pins	14
Supplier Device Package	14-SOIC
Mounting Style	SMD/SMT
Interfaces	I2C/LIN/RS-232/RS-48
Number of I/Os	12 I/O
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	PIC
RoHS	Details
Package	Tube
Base Product Number	PIC16LF1704
Mfr	Microchip Technology
Data Converters	A/D 8x10b; D/A 1x8b
Product Status	Active
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Series	PIC® XLP™ 16F
Published	2013
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	14
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn)
Additional Feature	IT ALSO OPERATES IN 16MHZ AT 1.8V MIN SUPPLY
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	1.27mm
Frequency	32MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC16LF1704
Operating Supply Voltage	3.6V
Power Supplies	2/3.3V
Interface	I2C, LIN, RS-232, SPI, UART, USART
Memory Size	7kB
Oscillator Type	Internal
Number of I/O	12
Speed	32MHz
RAM Size	512 x 8
Voltage - Supply (Vcc/Vdd)	1.8V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	7KB 4K x 14
Connectivity	I2C, LINbus, SPI, UART/USART
Bit Size	8
Data Converter	A/D 8x10b; D/A 1x8b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	YES
Number of Timers/Counters	5
Product Type	8-bit Microcontrollers - MCU
ROM (words)	4096
EEPROM Size	-
On Chip Program ROM Width	14
CPU Family	PIC
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC16LF1704-E/SL Product Details

PIC16LF1704-E/SL Overview

This Microcontroller comes in a 14-SOIC (0.154, 3.90mm Width) package. This Microcontroller has 12 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 8-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~125°C TA Operating Temperature. Microcontroller runs in PIC® XLP™ 16F Series. The size of the program memory of Microcontroller is 7KB 4K x 14. MCU is powered by PIC Core Processor. The device belongs to MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs Type. The MCU has a number of 14 terminals. Microcontroller comes with 8 bit size. The component always operates in 3.3V supply voltage. MCU chip has NO DMA channels. The part owns 7kB memory size. You can find alternatives through the base part number PIC16LF1704. MCU's frequency is 32MHz. The device works in YES PWM channels. The pin number of the component remains 14. It has 5 timers/counters. The device is embedded with PIC CPU family. To name a few, there are additional features like IT ALSO OPERATES IN 16MHZ AT 1.8V MIN SUPPLY.
