Name: MIC5318-3.3YD5-TR
Brand: Microchip Technology
SKU: MIC5318-3.3YD5-TR
Price: 0.80000 USD
Availability: InStock

new-10%

MIC5318-3.3YD5-TR

Manufacturer part number:MIC5318-3.3YD5-TR

Manufacturer:Microchip Technology

Description:Enable Fixed 0.95 mm MIC5318 PMIC -- Series 5 SOT-23-5 Thin, TSOT-23-5

Case Package:SOT-23

Datasheet:MIC5318-3.3YD5-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	18 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	SOT-23-5 Thin, TSOT-23-5
Surface Mount	YES
Number of Pins	23
Supplier Device Package	TSOT-23-5
Number of Terminals	5
Mounting Style	SMD/SMT
Polarity Type	Positive
Regulator Output Type	Fixed
Voltage Regulator Type	LDO
Dropout Voltage@Current (Max)	0.1@150mA/0.2@300mA
Operating Temperature Classification	Automotive
Package Type	TSOT-23
Dropout Voltage@Current (Typ)	0.017@50mA
Operating Temp Range	-40C to 125C
Rad Hardened	No
Mounting	Surface Mount
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MIC5318
Mfr	Microchip Technology
Product Status	Active
MSL	MSL 1 - Unlimited
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package Shape	RECTANGULAR
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	--
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Type	LDO
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Technology	CMOS
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.95 mm
Reach Compliance Code	compliant
Base Part Number	MIC5318
Pin Count	5
JESD-30 Code	R-PDSO-G5
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	6V
Output Voltage	3.3V
Output Type	Fixed
Max Output Current	300mA
Polarity	Positive
Output Configuration	Positive
Output Current	300(mA)
Current - Output	300mA
Quiescent Current	85μA
Control Features	Enable
Accuracy	2 %
Input Voltage (Min)	2.3(V)
Voltage - Output (Min/Fixed)	3.3V
Topology	LDO
Number of Regulators	1
Min Input Voltage	2.3V
Protection Features	Over Current, Over Temperature
Current - Quiescent (Iq)	150μA
Voltage Dropout (Max)	0.2V @ 300mA
Max Input Voltage	6V
PSRR	75dB ~ 55dB (1kHz ~ 20kHz)
Seated Height-Max	1 mm
Dropout Voltage	110mV
Product Type	LDO Voltage Regulators
Output Voltage1-Max	3.399 V
Output Voltage1-Min	3.201 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	0.3 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.2 V
Min Current Limit	340mA
Operating Temperature TJ-Max	125 °C
Output Voltage Accuracy	±2 %
Line Regulation	0.02%/V
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	3.3 V
Load Regulation	0.2%
Input Voltage	6(V)
Product Category	LDO Voltage Regulators
Quiescent Current (Max)	0.15 mA
Output Voltage Range	-
Height	870μm
Length	2.9mm
Width	1.6mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MIC5318-3.3YD5-TR Product Details

MIC5318-3.3YD5-TR Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a SOT-23-5 Thin, TSOT-23-5 package. The IC chip's output type is Fixed. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 300mA. IC voltage regulator has a sum of 5 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 23. FYI, the basic part number for this IC regulator is MIC5318. This regulator IC is a typical PMIC - Power Management ICs. The regulator type for this IC regulator is FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR. It works in 300mA output current at mostIt operates in the 85μA Quiescent Current state. It is part of the -- Series. The regulator operates with a maximum operating temperature of 125°C. At the very least, the voltage regulator IC works with a -40°C operating temperature.
