Name: MIC5207BM5-TR
Brand: Microchip Technology
SKU: MIC5207BM5-TR
Availability: InStock

new-10%

MIC5207BM5-TR

Manufacturer part number:MIC5207BM5-TR

Manufacturer:Microchip Technology

Description:Enable Adjustable 0.95 mm MIC5207 PMIC -- Series 5 SC-74A, SOT-753

Case Package:SOT-23

Datasheet:MIC5207BM5-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	SC-74A, SOT-753
Surface Mount	YES
Supplier Device Package	SOT-23-5
Number of Terminals	5
Package	Tape & Reel (TR)
Base Product Number	MIC5207
Mfr	Microchip Technology
Product Status	Discontinued at Digi-Key
Package Shape	RECTANGULAR
Manufacturer	Microchip Technology Inc
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	--
JESD-609 Code	e0
Part Status	Discontinued
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn85Pb15)
HTS Code	8542.39.00.01
Subcategory	Other Regulators
Packing Method	TAPE AND REEL
Technology	BIPOLAR
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	240
Number of Functions	1
Terminal Pitch	0.95 mm
Reach Compliance Code	not_compliant
Base Part Number	MIC5207
Pin Count	5
JESD-30 Code	R-PDSO-G5
Current - Supply (Max)	3μA
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	16V
Output Type	Adjustable
Output Configuration	Positive
Current - Output	180mA
Control Features	Enable
Voltage - Output (Min/Fixed)	1.8V
Number of Regulators	1
Protection Features	Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq)	170μA
Voltage Dropout (Max)	0.4V @ 150mA
PSRR	--
Seated Height-Max	1.45 mm
Dropout Voltage1-Nom	0.165 V
Output Voltage1-Max	16 V
Output Voltage1-Min	1.2 V
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	0.18 A
Voltage - Output (Max)	15V
Dropout Voltage1-Max	0.4 V
Operating Temperature TJ-Max	125 °C
Adjustability	ADJUSTABLE
Load Regulation-Max(%)	0.7%
Line Regulation-Max (%/V)	0.1
Operating Temperature TJ-Min	-40 °C
Width	1.625 mm
Length	2.91 mm
RoHS Status	Non-RoHS Compliant

MIC5207BM5-TR Product Details

MIC5207BM5-TR Overview

In the case of Tape & Reel (TR) cases, the regulater IC is delivered. Packaging of the Liner regulator IC takes the form of a SC-74A, SOT-753 case. Adjustable is the Voltage Regulator Chip's output type. Linear IC consists of 1 battery regulators. The range of operating temperatures of Surface Mount are programmable in the Voltage Regulator Chip, so that the temperature can be varied as desired. Keeping the temperature at -40°C~125°C degrees is necessary for this regulator to function. There is an output function of Positive configured for this regulator. Currently, 180mA are being output by it at the moment. The sum of the pins in this unit is 5. The part includes 1 outputs in order to ensure that the voltage regulator IC performs effectively and in a timely manner. Here's the basic part number for this IC regulator: MIC5207. This voltage regulator IC is what is known as a standard Other Regulators component. This device has a regulator type called ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR, which means it operates on a DC voltage. Packing the voltage regulator IC is done in a method called TAPE AND REEL. The phone is a member of the -- Series.
