Name: MIC5205-3.6YM5-TR
Brand: Microchip Technology
SKU: MIC5205-3.6YM5-TR
Price: 0.54000 USD
Availability: InStock

new-10%

MIC5205-3.6YM5-TR

Manufacturer part number:MIC5205-3.6YM5-TR

Manufacturer:Microchip Technology

Description:Enable Fixed 0.95 mm MIC5205 PMIC -- Series 5 SC-74A, SOT-753

Case Package:SOT-23

Datasheet:MIC5205-3.6YM5-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	SC-74A, SOT-753
Surface Mount	YES
Number of Pins	5
Supplier Device Package	SOT-23-5
Number of Terminals	5
Mounting Style	SMD/SMT
Supplier Package	SOT-23
Junction to Case	130 °C/W
Input Voltage Range	2.5, 16 V
Maximum Input Voltage	16 V
Junction to Ambient	220 °C/W
Mounting	Surface Mount
MSL	MSL 1 - Unlimited
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MIC5205
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	--
Tolerance	1 %
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	5
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory	PMIC - Power Management ICs
Packing Method	TAPE AND REEL
Terminal Position	DUAL
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.95 mm
Reach Compliance Code	compliant
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	MIC5205
Pin Count	5
JESD-30 Code	R-PDSO-G5
Function	LDO
Current - Supply (Max)	2.5mA
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	16V
Output Voltage	3.6V
Output Type	Fixed
Max Output Current	150mA
Polarity	Positive
Output Configuration	Positive
Output Current	0.15 A
Current - Output	150mA
Quiescent Current	5μA
Control Features	Enable
Accuracy	2 %
Output Voltage 1	3.6V
Voltage - Output (Min/Fixed)	3.6V
Number of Regulators	1
Min Input Voltage	2.5V
Protection Features	Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq)	150μA
Voltage Dropout (Max)	0.35V @ 150mA
PSRR	75dB (100Hz)
Seated Height-Max	1.45 mm
Dropout Voltage	165mV
Product Type	LDO Voltage Regulators
Dropout Voltage1-Nom	0.165 V
Min Output Voltage	3.6V
Power Supply Rejection Ratio (PSRR)	75dB
Output Voltage1-Max	3.672 V
Output Voltage1-Min	3.528 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max	2%
Output Current1-Max	0.15 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.35 V
Screening Level	Extended Industrial
Operating Temperature TJ-Max	125 °C
Input Voltage Absolute-Max	20 V
Nominal Output Voltage	3.6V
Adjustability	FIXED
Line Regulation	0.012 %/V
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	3.6 V
Load Regulation	0.2 %
Product Category	LDO Voltage Regulators
Height	1.3mm
Length	3.02mm
Width	1.75mm
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MIC5205-3.6YM5-TR Product Details

MIC5205-3.6YM5-TR Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. Packaged in a SC-74A, SOT-753 case, the battery regulator IC is protected from damage during shipment. There are 5 terminations on the gadget. The IC chip's output type is Fixed. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 150mA. There are totally 5 pins on this chip. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 5. FYI, the basic part number for this IC regulator is MIC5205. This regulator IC is a typical PMIC - Power Management ICs. The regulator type for this IC regulator is FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR. The way of packing the voltage regulator IC is TAPE AND REEL. It works in 150mA output current at mostIt operates in the 5μA Quiescent Current state. It is part of the -- Series. Speaking of tolerance, this voltage regulator IC is characterized to have 1 % tolerance, which is quite low.
