Name: MIC2940A-3.3WU-TR
Brand: Microchip Technology
SKU: MIC2940A-3.3WU-TR
Price: 2.68000 USD
Availability: InStock

new-10%

MIC2940A-3.3WU-TR

Manufacturer part number:MIC2940A-3.3WU-TR

Manufacturer:Microchip Technology

Description:-- Fixed 2.54 mm MIC2940A-3.3 PMIC -- Series TO-263-4, D2Pak (3 Leads + Tab), TO-263AA

Case Package:SOT-23

Datasheet:MIC2940A-3.3WU-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Surface Mount	YES
Supplier Device Package	TO-263-3
Number of Terminals	3
Mounting Style	SMD/SMT
Junction to Case	2 °C/W
Input Voltage Range	2 to 26 V
Maximum Input Voltage	26 V
Mounting	Surface Mount
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	MIC2940
Mfr	Microchip Technology
Product Status	Active
Package Shape	RECTANGULAR
Operating Temperature	-40°C~125°C
Packaging	Tape & Reel (TR)
Series	--
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
ECCN Code	EAR99
Type	Low Quiescent Current
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
HTS Code	8542.39.00.01
Subcategory	PMIC - Power Management ICs
Technology	BIPOLAR
Terminal Position	SINGLE
Terminal Form	GULL WING
Peak Reflow Temperature (Cel)	245
Number of Functions	1
Terminal Pitch	2.54 mm
Reach Compliance Code	not_compliant
Base Part Number	MIC2940A-3.3
JESD-30 Code	R-PSSO-G3
Function	LDO
Current - Supply (Max)	70mA
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	26V
Output Voltage	3.3V
Output Type	Fixed
Max Output Current	1.25A
Polarity	Positive
Output Configuration	Positive
Output Current	1.25 A
Current - Output	1.25A
Quiescent Current	500μA
Control Features	--
Voltage - Output (Min/Fixed)	3.3V
Number of Regulators	1
Min Input Voltage	2V
Protection Features	Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq)	500μA
Voltage Dropout (Max)	0.6V @ 1.25A
Max Input Voltage	26V
PSRR	--
Reference Voltage	1.247 V
Seated Height-Max	4.902 mm
Dropout Voltage	400mV
Product Type	LDO Voltage Regulators
Min Output Voltage	3.3V
Output Voltage1-Max	3.3825 V
Output Voltage1-Min	3.2175 V
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Current1-Max	1.25 A
Voltage - Output (Max)	--
Dropout Voltage1-Max	0.6 V
Screening Level	Extended Industrial
Operating Temperature TJ-Max	125 °C
Output Voltage Accuracy	1 %
Line Regulation	0.5 %
Operating Temperature TJ-Min	-40 °C
Output Voltage1-Nom	3.3 V
Load Regulation	0.2 %
Product	LDO Voltage Regulators
Product Category	LDO Voltage Regulators
Output Voltage Range	-
Width	8.7755 mm
Length	10.363 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MIC2940A-3.3WU-TR Product Details

MIC2940A-3.3WU-TR Overview

This Voltage Regulator IC comes inTape & Reel (TR) packaging. This battery regulator is contained in a TO-263-4, D2Pak (3 Leads + Tab), TO-263AA package. The IC chip's output type is Fixed. This electronic component implements 1 regulators. The Linear Voltage Regulator's mounting type is Surface Mount. The IC Regulator is set to operate at -40°C~125°C degrees. This regulator's output function is configured to be Positive. Its current output stands at 1.25A. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. FYI, the basic part number for this IC regulator is MIC2940A-3.3. This regulator IC is a typical PMIC - Power Management ICs. The regulator type for this IC regulator is FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR. It works in 1.25A output current at mostIt operates in the 500μA Quiescent Current state. It is part of the -- Series. The regulator operates with a maximum operating temperature of 125°C. At the very least, the voltage regulator IC works with a -40°C operating temperature.
