Name: DSPIC33EP256MC206T-I/MR
Brand: Microchip Technology
SKU: DSPIC33EP256MC206T-I/MR
Availability: InStock

new-10%

DSPIC33EP256MC206T-I/MR

Manufacturer part number:DSPIC33EP256MC206T-I/MR

Manufacturer:Microchip Technology

Description:256KB 85.5K x 24 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 33EP Series DSPIC33EP256MC206 64 Pin 70MHz 3.3V 64-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33EP256MC206T-I/MR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	64-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	64
Supplier Device Package	64-QFN (9x9)
Number of Terminals	64
Data Converters	A/D 16x10b/12b
Package	Tape & Reel (TR)
Base Product Number	DSPIC33EP256MC206
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	53
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	dsPIC™ 33EP
Published	2013
JESD-609 Code	e3
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	64
ECCN Code	3A001.A.3
Terminal Finish	Matte Tin (Sn) - annealed
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	0.5 mm
Reach Compliance Code	compliant
Frequency	70MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC33EP256MC206
Pin Count	64
JESD-30 Code	S-PQCC-N64
Qualification Status	Not Qualified
Operating Supply Voltage	3.3V
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	3.3 V
Temperature Grade	INDUSTRIAL
Interface	I2C, IrDA, LIN, SPI, UART, USART
Memory Size	256kB
Oscillator Type	Internal
Number of I/O	53
Speed	70 MIPs
RAM Size	16K x 16
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	256KB 85.5K x 24
Connectivity	I2C, IrDA, LINbus, QEI, SPI, UART/USART
Supply Current-Max	60 mA
Bit Size	16
Data Converter	A/D 16x10b/12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	5
ROM (words)	87381
EEPROM Size	--
On Chip Program ROM Width	24
Format	FLOATING-POINT
RAM (words)	16384
RAM (bytes)	32768
ROM Programmability	FLASH
Length	9mm
Height Seated (Max)	1mm
Width	9 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

DSPIC33EP256MC206T-I/MR Product Details

DSPIC33EP256MC206T-I/MR Overview

The package is 64-VFQFN Exposed Pad-shaped. There are 53 I/Os. In the case of the IC chip, the type of mounting is Surface Mount. Microcontroller is based on the 16-Bit core architecture. The type of program memory it uses is FLASH. Temperatures in the range of -40°C~85°C TA are operated by this Microcontroller. It is part of the dsPIC™ 33EP series of electrical components. Having a size of 256KB 85.5K x 24, Microcontroller has a program memory of X bytes. A dsPIC Core Processor is at the core of this Microcontroller. This device belongs to the MICROCONTROLLER uPs/uCs/Peripheral ICs category. IC Chip 64 has 64 terminations. 16-bits are used for its size. IC Chip has 3.3V volt supply outputs. With YES DMA channels, Microcontroller chip can handle large data transfers. 256kB is the size of the memory in the IC part. Using the base part number DSPIC33EP256MC206, you will be able to find alternatives for the part. Using a 70MHz frequency, this electronic part can perform efficiently. Devices work in YES PWM channels. On the chip, 64 pins are accessible. In total, there are 5 timers/counters on the device. The pin count is 64.
