Name: DSPIC33EP256GP504T-I/TL
Brand: Microchip Technology
SKU: DSPIC33EP256GP504T-I/TL
Availability: InStock

new-10%

DSPIC33EP256GP504T-I/TL

Manufacturer part number:DSPIC33EP256GP504T-I/TL

Manufacturer:Microchip Technology

Description:256KB 85.5K x 24 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 33EP Series DSPIC33EP256GP504 44 Pin 70MHz 3.3V 44-VFTLA Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC33EP256GP504T-I/TL Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	20 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-VFTLA Exposed Pad
Surface Mount	YES
Number of Pins	44
Supplier Device Package	44-VTLA (6x6)
Number of Terminals	44
Data Converters	A/D 9x10b/12b
Package	Tape & Reel (TR)
Base Product Number	DSPIC33EP256GP504
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	35
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	dsPIC™ 33EP
Published	2012
JESD-609 Code	e4
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	44
ECCN Code	3A001.A.3
Terminal Finish	NICKEL PALLADIUM GOLD
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Terminal Pitch	0.5 mm
Reach Compliance Code	compliant
Frequency	70MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC33EP256GP504
Pin Count	44
JESD-30 Code	S-XQCC-N44
Qualification Status	Not Qualified
Operating Supply Voltage	3.3V
Supply Voltage-Max (Vsup)	3.6V
Power Supplies	3.3 V
Temperature Grade	INDUSTRIAL
Interface	CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size	256kB
Oscillator Type	Internal
Number of I/O	35
Speed	70 MIPs
RAM Size	16K x 16
Voltage - Supply (Vcc/Vdd)	3V~3.6V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	256KB 85.5K x 24
Connectivity	CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max	150 mA
Bit Size	16
Data Converter	A/D 9x10b/12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	YES
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	5
ROM (words)	87381
EEPROM Size	--
On Chip Program ROM Width	24
Format	FLOATING-POINT
RAM (words)	16384
RAM (bytes)	32768
ROM Programmability	FLASH
Length	6mm
Height Seated (Max)	1mm
Width	6 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

DSPIC33EP256GP504T-I/TL Product Details

DSPIC33EP256GP504T-I/TL Overview

Packaged in a 44-VFTLA Exposed Pad format. A total of 35 I/Os are on the Microcontroller. Surface Mount is the mounting type of the Microcontroller that is attached to the panel. This Microcontroller is based on a core called 16-Bit. The type of its program memory is FLASH. In this Microcontroller, temperature is controlled within the range -40°C~85°C TA. A dsPIC™ 33EP series electrical component is used in this application. This program has a program memory of 256KB 85.5K x 24 bytes, which is the size of the program. With a dsPIC Core Processor, Microcontroller is fast and efficient. ICs for MICROCONTROLLER uPs/uCs/peripheral parts. There are 44 terminations on the IC chip, which means there are 44 terminations on the integrated circuit chip. In addition, MCU chip comes with a 16-bit size. Microcontroller chip has outputs of 3.3V volts. The system has YES channels for DMA communication. There is 256kB memory size assigned to the part. Alternatives can be found by searching through the base part number DSPIC33EP256GP504 to find them. At a frequency of 70MHz, Microcontroller can operate efficiently. This MCU Chip uses YES PWM channels to operate. Chips have 44 pins. There are 5 timers/counters in this device. In total, it has 44 pins.
