Name: DSPIC30F2011-20E/ML
Brand: Microchip Technology
SKU: DSPIC30F2011-20E/ML
Availability: InStock

new-10%

DSPIC30F2011-20E/ML

Manufacturer part number:DSPIC30F2011-20E/ML

Manufacturer:Microchip Technology

Description:12KB 4K x 24 FLASH dsPIC 16-Bit Microcontroller dsPIC™ 30F Series DSPIC30F2011 28 Pin 20MHz 5V 28-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:DSPIC30F2011-20E/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	28-VQFN Exposed Pad
Surface Mount	YES
Number of Pins	28
Supplier Device Package	28-QFN (6x6)
Number of Terminals	28
Data Converters	A/D 8x12b
RoHS	Compliant
Package	Tube
Base Product Number	DSPIC30F2011
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	12
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Series	dsPIC™ 30F
Published	2006
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	28
ECCN Code	3A991.A.2
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125 °C
Min Operating Temperature	-40 °C
Additional Feature	ALSO OPERATES AT 3V MINIMUM SUPPLY AT 15MHZ
HTS Code	8542.31.00.01
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	5V
Terminal Pitch	0.65mm
Reach Compliance Code	compliant
Frequency	20MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	DSPIC30F2011
Pin Count	28
JESD-30 Code	S-PQCC-N28
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5 V
Temperature Grade	AUTOMOTIVE
Supply Voltage-Min (Vsup)	4.5V
Interface	I2C, SPI, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	3 V
Memory Size	12kB
Oscillator Type	Internal
Number of I/O	12
Speed	20 MIPS
RAM Size	1K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2.5V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	dsPIC
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	16-Bit
Program Memory Size	12KB 4K x 24
Connectivity	I2C, SPI, UART/USART
Bit Size	16
Data Converter	A/D 8x12b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	16b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	3
ROM (words)	4096
Core Architecture	dsPIC
EEPROM Size	--
On Chip Program ROM Width	24
Max Frequency	20 MHz
Number of Programmable I/O	12
Format	FIXED-POINT
RAM (words)	1024
RAM (bytes)	1024
ROM Programmability	FLASH
Length	6mm
Height Seated (Max)	1mm
Width	6 mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

DSPIC30F2011-20E/ML Product Details

DSPIC30F2011-20E/ML Overview

A 28-VQFN Exposed Pad package is included. In total, it has 12 inputs and outputs. This Microcontroller is mounted using the Surface Mount mounting type. Powered by the 16-Bit core, it offers a wide range of capabilities. The type of memory that the program uses is FLASH. The temperature range of this Microcontroller is within the range of -40°C~125°C TA. dsPIC™ 30F series components belong to this electrical component. Its program memory size is 12KB 4K x 24. There is a dsPIC Core Processor inside MCU that provides this device with its power. MICROCONTROLLER, RISC uPs, uCs, and peripheral ICs make up the Microcontroller. Microcontroller is known that the chip has 28 terminations in total. The part works on a 16-bit basis. An output voltage of 5V volts is available for this Microcontroller chip. The Microcontroller chip has NO DMA channels. 12kB memory size belongs to the part. DSPIC30F2011 is the base part number that you can use to find alternatives. A good performance can be achieved at a frequency of 20MHz, as long as it is operated at a low power consumption. In order for the device to work with the motor, it utilizes the PWM channel YES. On the chip, there are 28 pins that are accessible. A total of 3 timers/counters are included in the package. A total of 28 pins are present. There's built-in FLASH memory in the equipment. It is built on a dsPIC core architecture. This 8 Programmable I/O section allows you to program the device in many different ways depending on what you need. As a few examples, there are additional features like ALSO OPERATES AT 3V MINIMUM SUPPLY AT 15MHZ that are available in the software.
