Name: C8051F022
Brand: Silicon Labs
SKU: C8051F022
Availability: InStock

new-10%

C8051F022

Manufacturer part number:C8051F022

Manufacturer:Silicon Labs

Description:64KB 64K x 8 FLASH 8051 8-Bit Microcontroller C8051F02x Series C8051F02 100 Pin 25MHz 100-TQFP

Case Package:SOT-23

Datasheet:C8051F022 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	100-TQFP
Number of Pins	100
Supplier Device Package	100-TQFP (14x14)
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	C8051F02x
Published	2000
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Max Operating Temperature	85°C
Min Operating Temperature	-40°C
Frequency	25MHz
Base Part Number	C8051F02
Number of Channels	5
Interface	2-Wire, EBI/EMI, I2C, SMBus, SPI, UART, USART
Max Supply Voltage	3.6V
Min Supply Voltage	2.7V
Memory Size	64kB
Oscillator Type	Internal
Number of I/O	64
Speed	25MHz
RAM Size	4.25K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2.7V~3.6V
Core Processor	8051
Peripherals	Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	64KB 64K x 8
Connectivity	EBI/EMI, SMBus (2-Wire/I2C), SPI, UART/USART
Data Converter	A/D 8x8b, 8x10b; D/A 2x12b
Access Time	25 μs
Data Bus Width	8b
Number of Timers/Counters	5
Core Architecture	8051
Max Frequency	25MHz
Number of Programmable I/O	64
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Lead Free	Contains Lead

C8051F022 Product Details

C8051F022 Overview

This Microcontroller comes in a 100-TQFP package. This Microcontroller has 64 I/Os. The Mounting Type of the Microcontroller is Surface Mount. The MCU is based on the 8-Bit core. This Microcontroller's program memory type is FLASH. The Microcontroller runs in -40°C~85°C TA Operating Temperature. Microcontroller runs in C8051F02x Series. The size of the program memory of Microcontroller is 64KB 64K x 8. MCU is powered by 8051 Core Processor. The part owns 64kB memory size. You can find alternatives through the base part number C8051F02. MCU's frequency is 25MHz. The pin number of the component remains 100. It has 5 timers/counters. This equipment features FLASH memory. It has a 8051 core architecture integrated into it. It programs in 64 Programmable I/O.
