Name: AVR128DA64-I/MR
Brand: Microchip Technology
SKU: AVR128DA64-I/MR
Price: 2.98000 USD
Availability: InStock

new-10%

AVR128DA64-I/MR

Manufacturer part number:AVR128DA64-I/MR

Manufacturer:Microchip Technology

Description:128KB Flash AVR 8-Bit Microcontroller AVR® DA Series 64-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:AVR128DA64-I/MR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	64-VFQFN Exposed Pad
Mounting Type	Surface Mount
Supplier Device Package	64-VQFN (9x9)
Mounting Style	SMD/SMT
ECCN (US)	EAR99
HTS	8542.31.00.01
Instruction Set Architecture	RISC
Maximum CPU Frequency (MHz)	24
Maximum Clock Rate (MHz)	24
Data Bus Width (bit)	8
Programmability	Yes
Interface Type	CAN/I2C/SPI/USART
No. of Timers	8
Number of ADCs	Single
ADC Resolution (bit)	12
Number of DACs	Single
DAC Resolution (bit)	10
USART	6
UART	0
I2C	2
I2S	0
Minimum Operating Supply Voltage (V)	1.8
Typical Operating Supply Voltage (V)	2.5\|5\|3.3
Maximum Operating Supply Voltage (V)	5.5
Maximum Power Dissipation (mW)	800
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Supplier Temperature Grade	Industrial
Supplier Package	QFN EP
Mounting	Surface Mount
Package Height	0.88
Package Length	9
Package Width	9
PCB changed	64
Interfaces	Serial I2C/SPI/UART
MSL	MSL 1 - Unlimited
Qualification	-
Number of I/Os	55 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
RoHS	Details
Product Status	Active
Data Converters	A/D 22x12b; D/A 1x10b
Mfr	Microchip Technology
Base Product Number	AVR128DA64
Package	Tray
Packaging	Tray
Series	AVR® DA
Operating Temperature	-40°C ~ 85°C (TA)
Part Status	Active
Subcategory	Microcontrollers - MCU
Reach Compliance Code	compliant
Pin Count	64
Oscillator Type	Internal
Number of I/O	55
Speed	24MHz
RAM Size	16KB
Voltage - Supply (Vcc/Vdd)	1.8V ~ 5.5V
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	Flash
Core Size	8-Bit
Program Memory Size	128KB
Connectivity	I²C, SPI, UART/USART
Data Bus Width	8 bit
DAC Channels	1
Product Type	8-bit Microcontrollers - MCU
Core Architecture	AVR
EEPROM Size	512 x 8
Ethernet	0
USB	0
SPI	2
Product Category	8-bit Microcontrollers - MCU
Device Core	AVR
RoHS Status	RoHS Compliant

AVR128DA64-I/MR Product Details

AVR128DA64-I/MR Overview

There is a 64-VFQFN Exposed Pad package available. The board has 55 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 8-Bit core is used in order to power the IC chip. The type of memory it uses for its program is Flash. -40°C ~ 85°C (TA) is the temperature range at which this Microcontroller operates. AVR® DA-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 128KB. Powered by a AVR Core processor. The pins counted are 64. The CPU is based on AVR cores.
