Name: ATTINY25-15MT
Brand: Microchip Technology
SKU: ATTINY25-15MT
Availability: InStock

new-10%

ATTINY25-15MT

Manufacturer part number:ATTINY25-15MT

Manufacturer:Microchip Technology

Description:2KB 1K x 16 FLASH AVR 8-Bit Microcontroller Automotive, AEC-Q100, AVR® ATtiny Series ATTINY25 20 Pin 16MHz 5V 20-WFQFN Exposed Pad

Case Package:SOT-23

Datasheet:ATTINY25-15MT Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	20-WFQFN Exposed Pad
Surface Mount	YES
Number of Pins	20
Supplier Device Package	20-WQFN (4x4)
Number of Terminals	20
Interfaces	SPI/USI
Data Converters	A/D 4x10b
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATTINY25
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Manufacturer	Microchip Technology Inc
Number of I/O Lines	6
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	Automotive, AEC-Q100, AVR® ATtiny
Published	2011
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	20
Additional Feature	ALSO OPERATES AT 2.7V MINIMUM SUPPLY AT 8 MHZ
Terminal Position	QUAD
Terminal Form	NO LEAD
Supply Voltage	5V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	16MHz
Base Part Number	ATTINY25
JESD-30 Code	S-XQCC-N20
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	4.5V
Interface	SPI, UART
Memory Size	2kB
Oscillator Type	Internal
Number of I/O	6
Speed	16MHz
RAM Size	128 x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	2KB 1K x 16
Connectivity	USI
Supply Current-Max	15 mA
Bit Size	8
Data Converter	A/D 4x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	0.8 mm
Number of Timers/Counters	2
ROM (words)	2048
EEPROM Size	128 x 8
CPU Family	AVR RISC
RAM (bytes)	128
ROM Programmability	FLASH
Device Core	AVR
Length	4mm
Height Seated (Max)	0.8mm
Width	4 mm
RoHS Status	ROHS3 Compliant

ATTINY25-15MT Product Details

ATTINY25-15MT Overview
