Name: ATMEGA88-20MU
Brand: Microchip Technology
SKU: ATMEGA88-20MU
Price: 3.62000 USD
Availability: InStock

new-10%

ATMEGA88-20MU

Manufacturer part number:ATMEGA88-20MU

Manufacturer:Microchip Technology

Description:8KB 4K x 16 FLASH AVR 8-Bit Microcontroller AVR® ATmega Series ATMEGA88 32 Pin 20MHz 3V 32-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:ATMEGA88-20MU Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	32-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	32
Supplier Device Package	32-VQFN (5x5)
Number of Terminals	32
Mounting Style	SMD/SMT
Interfaces	SPI/TWI/USART
Data Converters	A/D 8x10b
Family Name	Microcontrollers
Package Type	32M1-A
MSL	MSL 1 - Unlimited
Qualification	-
Schedule B	8542310000
Number of I/Os	23
RoHS	Compliant
DAC Resolution	-
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	I2C, SPI, USART
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	AVR
Package	Tray
Base Product Number	ATMEGA88
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	23
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	AVR® ATmega
Published	1997
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	32
Termination	SMD/SMT
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	20MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	ATMEGA88
Pin Count	32
JESD-30 Code	S-PQCC-N32
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5 V
Temperature Grade	INDUSTRIAL
Supply Voltage-Min (Vsup)	2.7V
Interface	2-Wire, I2C, SPI, Serial, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	2.7 V
Memory Size	8kB
Oscillator Type	Internal
Number of I/O	23
Speed	20MHz
RAM Size	1K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Number of Bits	8
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	8KB 4K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	12 mA
Bit Size	8
Data Converter	A/D 8x10b
Watchdog Timer	Yes
Access Time	20 μs
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	3
Product Type	8-bit Microcontrollers - MCU
Density	64 kb
ROM (words)	4096
Core Architecture	AVR
EEPROM Size	512 x 8
On Chip Program ROM Width	16
CPU Family	AVR RISC
Max Frequency	20 MHz
Boundary Scan	NO
Low Power Mode	YES
Number of Programmable I/O	23
Format	FIXED-POINT
Integrated Cache	NO
RAM (words)	1024
RAM (bytes)	1024
Number of ADC Channels	8
Number of Serial I/Os	1
Number of Timers	3
ROM Programmability	FLASH
Number of External Interrupts	2
Number of PWM Channels	6
Number of I2C Channels	1
On Chip Data RAM Width	8
Number of SPI Channels	1
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	AVR
Height	1mm
Length	4.8mm
Width	4.8mm
REACH SVHC	No SVHC
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

ATMEGA88-20MU Product Details

ATMEGA88-20MU Overview

The package is 32-VFQFN Exposed Pad-shaped. There are 23 I/Os. In the case of the IC chip, the type of mounting is Surface Mount. Microcontroller is based on the 8-Bit core architecture. The type of program memory it uses is FLASH. Temperatures in the range of -40°C~85°C TA are operated by this Microcontroller. It is part of the AVR® ATmega series of electrical components. Having a size of 8KB 4K x 16, Microcontroller has a program memory of X bytes. A AVR Core Processor is at the core of this Microcontroller. This device belongs to the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. IC Chip 32 has 32 terminations. 8-bits are used for its size. IC Chip has 3V volt supply outputs. With NO DMA channels, Microcontroller chip can handle large data transfers. 8kB is the size of the memory in the IC part. Using the base part number ATMEGA88, you will be able to find alternatives for the part. Using a 20MHz frequency, this electronic part can perform efficiently. Devices work in YES PWM channels. On the chip, 32 pins are accessible. In total, there are 3 timers/counters on the device. The pin count is 32. There is an embedded the AVR RISC CPU family inside the device, which makes it a powerful device. There is FLASH memory on this piece of equipment. In addition, it comes with a AVR core architecture. It has 23 Programmable Input/Output pins that can be programmed. The ADC channel count on this device totals up to 8 channels. IC chip bits total 8. In order for the device to function, it uses 6 PWM channels. 1 I2C channels are integrated by the part. This part has 1 serial I/Os that are integrated into it. A total of 2 external interrupts are included in the Microcontroller as well. IC chip bits total 3.
