Name: ATMEGA168P-20ANR
Brand: Microchip Technology
SKU: ATMEGA168P-20ANR
Price: 3.98000 USD
Availability: InStock

new-10%

ATMEGA168P-20ANR

Manufacturer part number:ATMEGA168P-20ANR

Manufacturer:Microchip Technology

Description:16KB 8K x 16 FLASH AVR 8-Bit Microcontroller AVR® ATmega Series ATMEGA168P 32 Pin 20MHz 32-TQFP

Case Package:SOT-23

Datasheet:ATMEGA168P-20ANR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	32-TQFP
Surface Mount	YES
Number of Pins	32
Supplier Device Package	32-TQFP (7x7)
Number of Terminals	32
Mounting Style	SMD/SMT
Interfaces	SPI/TWI/USART
Data Converters	A/D 8x10b
Number of I/Os	23 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	AVR
RoHS	Details
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATMEGA168
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	23
Operating Temperature	-40°C~105°C TA
Packaging	Tape & Reel (TR)
Series	AVR® ATmega
Published	2012
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Subcategory	Microcontrollers - MCU
Technology	CMOS
Terminal Position	QUAD
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Reach Compliance Code	unknown
Frequency	20MHz
Base Part Number	ATMEGA168P
JESD-30 Code	S-PQFP-G32
Temperature Grade	INDUSTRIAL
Interface	I2C, SPI, UART, USART
Memory Size	8kB
Oscillator Type	Internal
Number of I/O	23
Speed	20MHz
RAM Size	1K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	16KB 8K x 16
Connectivity	I2C, SPI, UART/USART
Supply Current-Max	9 mA
Bit Size	8
Data Converter	A/D 8x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1.2 mm
Number of Timers/Counters	3
Product Type	8-bit Microcontrollers - MCU
ROM (words)	16384
EEPROM Size	512 x 8
On Chip Program ROM Width	8
CPU Family	AVR RISC
Boundary Scan	NO
Low Power Mode	YES
Screening Level	TS 16949
Integrated Cache	NO
RAM (words)	16384
RAM (bytes)	1024
Number of Timers	5
ROM Programmability	FLASH
On Chip Data RAM Width	8
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	AVR
Width	7 mm
Length	7 mm
RoHS Status	ROHS3 Compliant

ATMEGA168P-20ANR Product Details

ATMEGA168P-20ANR Overview

Packaged in a 32-TQFP format, this MCU is available in a compact size. There are 23 I/Os on the Microcontroller. It is important to note that the Microcontroller has a Surface Mount mounting type. 8-Bit core is the basis for this Microcontroller. This program has a type of memory called FLASH for this MCU's program memory. Temperatures in this range are operated by this Microcontroller. The AVR® ATmega series includes this electrical component. There is 16KB 8K x 16 bytes of program memory in MCU, which corresponds to the size of the program. With a AVR Core processor, MCU is equipped with the latest technology available. This is a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. 8-bits are used in Microcontroller. Currently, MCU chip has NO DMA channels. 8kB memory size belongs to the Chip part. Alternatives can be found by looking at the base part number ATMEGA168P. In the case of 20MHz frequency operation, it can perform efficiently. There are YES PWM channels on the device. The chip has 32 pins. The clock has 3 timers/counters to keep track of the time. This device is embedded with a AVR RISC processor family, which is a powerful and efficient CPU. There are 5 bits in total on an IC chip.
