Name: ATMEGA128-16MUR
Brand: Microchip Technology
SKU: ATMEGA128-16MUR
Price: 12.06000 USD
Availability: InStock

new

ATMEGA128-16MUR

Manufacturer part number:ATMEGA128-16MUR

Manufacturer:Microchip Technology

Description:128KB 64K x 16 FLASH AVR 8-Bit Microcontroller AVR® ATmega Series ATMEGA128 64 Pin 16MHz 5V 64-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:ATMEGA128-16MUR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	64-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	64
Supplier Device Package	64-QFN (9x9)
Number of Terminals	64
Mounting Style	SMD/SMT
Interfaces	JTAG/TWI/SPI/USART
Data Converters	A/D 8x10b
Number of I/Os	53 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	2-Wire, JTAG, SPI, USART
Manufacturer	Microchip
Brand	Microchip Technology / Atmel
Tradename	AVR
RoHS	Details
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	ATMEGA128
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	53
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	AVR® ATmega
Published	1997
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
Terminal Finish	Matte Tin (Sn)
Max Operating Temperature	85 °C
Min Operating Temperature	-40 °C
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	5V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	16MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	ATMEGA128
JESD-30 Code	S-XQCC-N64
Qualification Status	Not Qualified
Operating Supply Voltage	5V
Power Supplies	5V
Temperature Grade	INDUSTRIAL
Interface	2-Wire, CAN, EBI/EMI, I2C, SPI, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	4.5 V
Memory Size	64kB
Oscillator Type	Internal
Number of I/O	53
Speed	16MHz
RAM Size	4K x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	4.5V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	128KB 64K x 16
Connectivity	EBI/EMI, I2C, SPI, UART/USART
Supply Current-Max	19 mA
Bit Size	8
Data Converter	A/D 8x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
DAC Channels	NO
Seated Height-Max	1 mm
Number of Timers/Counters	4
Address Bus Width	16
Product Type	8-bit Microcontrollers - MCU
ROM (words)	65536
Core Architecture	AVR
EEPROM Size	4K x 8
On Chip Program ROM Width	16
CPU Family	AVR RISC
Max Frequency	16 MHz
Boundary Scan	YES
Low Power Mode	YES
External Data Bus Width	8
Number of Programmable I/O	53
Format	FIXED-POINT
Integrated Cache	NO
RAM (bytes)	4096
Number of Serial I/Os	2
Number of Timers	4
ROM Programmability	FLASH
Number of External Interrupts	8
On Chip Data RAM Width	8
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	AVR
Length	9mm
Height Seated (Max)	1mm
Width	9 mm
Height	0.88 mm
RoHS Status	ROHS3 Compliant

ATMEGA128-16MUR Product Details

ATMEGA128-16MUR Overview

There is a 64-VFQFN Exposed Pad package available. The board has 53 I/Os. Using the Mounting Type Surface Mount, the MCU is mounted on PCB. A 8-Bit core is used in order to power the IC chip. The type of memory it uses for its program is FLASH. -40°C~85°C TA is the temperature range at which this Microcontroller operates. AVR® ATmega-series components are electrical components. In the case of this Microcontroller, the memory size of the program is 128KB 64K x 16. Powered by a AVR Core processor. Microcontroller's a MICROCONTROLLER, RISC uPs/uCs/Peripheral IC. IC Chip terminations are 64. As a result, this Microcontroller comes with a 8-bit size. Input voltage for the chip is 5V volts. A total of NO DMA channels are available. This IC part has a memory size of 64kB. There are a number of alternatives to the base part number ATMEGA128 that you can find. Performing well when operated at frequency 16MHz can be achieved. Using YES PWM channels, the device works. On the chip, there are 64 pins that can be accessed. It comes with 4 timers/counters that can be set up. The device is powered by the the AVR RISC CPU family that is embedded in it. FLASH memory is one of the features of this equipment. The CPU is based on AVR cores. There are 53 Programmable I/Os on this computer. It contains 2 serial input/output interfaces on the board. The part contains 8 interrupts external to the system. The total number of bits on a MCU chip is 4.
