Name: PIC16F1937-E/ML
Brand: Microchip Technology
SKU: PIC16F1937-E/ML
Price: 2.90000 USD
Availability: InStock

new-10%

PIC16F1937-E/ML

Manufacturer part number:PIC16F1937-E/ML

Manufacturer:Microchip Technology

Description:14KB 8K x 14 FLASH PIC 8-Bit Microcontroller PIC® XLP™ 16F Series PIC16F1937 44 Pin 32MHz 3.3V 44-VQFN Exposed Pad

Case Package:SOT-23

Datasheet:PIC16F1937-E/ML Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	7 Weeks
Lifecycle Status	Production (Last Updated: 2 years ago)
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	44-VQFN Exposed Pad
Number of Pins	44
Supplier Device Package	44-QFN (8x8)
Mounting Style	SMD/SMT
Interfaces	I2C/SPI/USART
Data Converters	A/D 14x10b
Number of I/Os	36 I/O
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Interface Type	EUSART, MI2C, SPI
Manufacturer	Microchip
Brand	Microchip Technology
Tradename	PIC
RoHS	Details
Package	Tube
Base Product Number	PIC16F1937
Mfr	Microchip Technology
Product Status	Active
Operating Temperature	-40°C~125°C TA
Packaging	Tube
Series	PIC® XLP™ 16F
Published	2008
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	44
Terminal Finish	Matte Tin (Sn) - annealed
Max Operating Temperature	125 °C
Min Operating Temperature	-40 °C
Max Power Dissipation	800mW
Terminal Position	QUAD
Peak Reflow Temperature (Cel)	260
Supply Voltage	3.3V
Frequency	32MHz
Time@Peak Reflow Temperature-Max (s)	40
Base Part Number	PIC16F1937
Pin Count	44
Supply Voltage-Min (Vsup)	2.3V
Interface	I2C, LIN, SPI, UART, USART
Max Supply Voltage	5.5 V
Min Supply Voltage	1.8 V
Memory Size	14kB
Oscillator Type	Internal
Number of I/O	36
Speed	32MHz
RAM Size	512 x 8
Memory Type	FLASH
Voltage - Supply (Vcc/Vdd)	1.8V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	PIC
Peripherals	Brown-out Detect/Reset, LCD, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	14KB 8K x 14
Connectivity	I2C, LINbus, SPI, UART/USART
Supply Current-Max	8mA
Bit Size	8
Data Converter	A/D 14x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
Number of Timers/Counters	5
Product Type	8-bit Microcontrollers - MCU
Core Architecture	PIC
EEPROM Size	256 x 8
CPU Family	PIC
Max Frequency	32 MHz
Number of Programmable I/O	36
Number of UART Channels	1
Number of ADC Channels	14
Number of I2C Channels	1
Number of SPI Channels	1
Product	MCU
Product Category	8-bit Microcontrollers - MCU
Device Core	PIC
Height	950μm
Length	8mm
Width	8mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

PIC16F1937-E/ML Product Details

PIC16F1937-E/ML Overview

44-VQFN Exposed Pad-packages are available. There are 36 I/O ports on this device. Device mounting type Surface Mount is the type of mounting that the Microcontroller uses. There is a 8-Bit core at the core of this MCU. There is a type of program memory called FLASH in the Microcontroller. There is a temperature range of -40°C~125°C TA for this Microcontroller. An electrical component of this type belongs to the PIC® XLP™ 16F series. This program memory has a size of 14KB 8K x 14, which indicates what the size of the program memory is. PIC Core processors are used in MCU. Devices of this type belong to the MICROCONTROLLER, RISC power supply/socket/peripheral ICs category. This chip has a total of 44 terminations on MCU chip. You get a 8-bit size. This Microcontroller chip is powered by 3.3V volts. There are NO DMA channels on this Microcontroller chip. The part has a memory size of 14kB. The base part number PIC16F1937 provides alternatives. This device is extremely efficient when operated at a frequency of 32MHz. Using the PWM channel YES, the device works with the motor. In this chip, 44 pins can be accessed. Using the timer/counter system, it has 5 timers/counters. It has 44 pins in total. In addition to this, the device is embedded with the the PIC CPU family. There is FLASH memory in this equipment. As a result of its PIC core architecture, it can be used in many applications. This device has 36 programmable input and output channels. With 1 UART channels, it has all the features you may need. In total, it has 14 ADC channels for the measurement of signals. As part of the design, the part has been designed to feature 1 channels for I2C communication.
