Name: AT90USB1286-MUR
Brand: Microchip Technology
SKU: AT90USB1286-MUR
Price: 11.21000 USD
Availability: InStock

new

AT90USB1286-MUR

Manufacturer part number:AT90USB1286-MUR

Manufacturer:Microchip Technology

Description:128KB 128K x 8 FLASH AVR 8-Bit Microcontroller AVR® 90USB Series AT90USB1286 64 Pin 16MHz 5V 64-VFQFN Exposed Pad

Case Package:SOT-23

Datasheet:AT90USB1286-MUR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	4 Weeks
Contact Plating	Tin
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	64-VFQFN Exposed Pad
Surface Mount	YES
Number of Pins	64
Supplier Device Package	64-QFN (9x9)
Number of Terminals	64
Mounting Style	SMD/SMT
Interfaces	SPI/UART
Data Converters	A/D 8x10b
Number of I/Os	48 I/O
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Interface Type	SPI, UART
Manufacturer	Microchip
Brand	Microchip Technology
RoHS	Details
Package	Tape & Reel (TR);Cut Tape (CT);Digi-Reel®;
Base Product Number	AT90USB1286
Mfr	Microchip Technology
Product Status	Active
Package Shape	SQUARE
Number of I/O Lines	48
Operating Temperature	-40°C~85°C TA
Packaging	Tape & Reel (TR)
Series	AVR® 90USB
Published	2012
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	64
Terminal Position	QUAD
Terminal Form	NO LEAD
Supply Voltage	5V
Terminal Pitch	0.5mm
Reach Compliance Code	compliant
Frequency	16MHz
Base Part Number	AT90USB1286
JESD-30 Code	S-PQCC-N64
Qualification Status	Not Qualified
Supply Voltage-Max (Vsup)	5.5V
Power Supplies	3/5V
Temperature Grade	INDUSTRIAL
Interface	EBI/EMI, I2C, SPI, UART, USART, USB
Memory Size	128kB
Oscillator Type	Internal
Number of I/O	48
Speed	16MHz
RAM Size	8K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	AVR
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type	FLASH
Core Size	8-Bit
Program Memory Size	128KB 128K x 8
Connectivity	EBI/EMI, I2C, SPI, UART/USART, USB, USB OTG
Supply Current-Max	30 mA
Bit Size	8
Data Converter	A/D 8x10b
Watchdog Timer	Yes
Has ADC	YES
DMA Channels	NO
Data Bus Width	8b
PWM Channels	YES
Number of Timers/Counters	4
Address Bus Width	16
Product Type	8-bit Microcontrollers - MCU
ROM (words)	131072
EEPROM Size	4K x 8
CPU Family	AVR RISC
External Data Bus Width	8
RAM (bytes)	8192
ROM Programmability	FLASH
Product Category	8-bit Microcontrollers - MCU
Device Core	AVR
Length	9mm
Width	9 mm
Height	0.95 mm
RoHS Status	ROHS3 Compliant

AT90USB1286-MUR Product Details

AT90USB1286-MUR Overview

In a 64-VFQFN Exposed Pad package, the MCU is available. 48 I/Os are available. The Microcontroller has a mounting type of Surface Mount, which indicates that it is mounted conveniently. The 8-Bit core is the core of the MCU. There is a FLASH type of memory for its program. There is a temperature range of -40°C~85°C TA that is operated by this Microcontroller. AVR® 90USB series components make up this electrical component. 128KB 128K x 8 is the size of its program memory. A AVR Core processor is used to power the device. This device falls under the MICROCONTROLLER, RISC uPs/uCs/Peripheral ICs category. 64 is the number of terminations on the IC chip that are present. This part works in a 8-bit manner. There is a 5V volt supply output on the chip. DMA channels number NO. 128kB is the memory size of the part. The base part number AT90USB1286 can be used to find alternatives. The efficiency of this device can be improved when operating at a frequency of 16MHz. The device works in YES PWM channels. Located on the chip are 64 pins. The clock has 4 timers or counters on it. In this device, there is a AVR RISC CPU embedded within it.
