Name: MAX5087AATE+
Brand: Maxim Integrated
SKU: MAX5087AATE+
Availability: InStock

new-10%

MAX5087AATE+

Manufacturer part number:MAX5087AATE+

Manufacturer:Maxim Integrated

Description:Enable, Reset Adjustable (Fixed) 0.8mm MAX5087 PMIC 16 16-WQFN Exposed Pad

Case Package:SOT-23

Datasheet:MAX5087AATE+ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	6 Weeks
Mounting Type	Surface Mount
Package / Case	16-WQFN Exposed Pad
Surface Mount	YES
Operating Temperature	-40°C~125°C
Packaging	Tube
Published	2012
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	16
ECCN Code	EAR99
Terminal Finish	Matte Tin (Sn)
Terminal Position	QUAD
Terminal Form	NO LEAD
Peak Reflow Temperature (Cel)	260
Number of Functions	1
Terminal Pitch	0.8mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Base Part Number	MAX5087
Pin Count	16
Number of Outputs	1
Qualification Status	Not Qualified
Voltage - Input (Max)	45V
Output Type	Adjustable (Fixed)
Output Configuration	Positive
Current - Output	400mA
Control Features	Enable, Reset
Output Voltage 1	3.3V
Voltage - Output (Min/Fixed)	2.5V 3.3V
Number of Regulators	1
Protection Features	Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq)	150μA
Voltage Dropout (Max)	2.2V @ 400mA
PSRR	70dB (100Hz)
Dropout Voltage1-Nom	0.9V
Output Voltage1-Min	2.5V
Voltage Tolerance-Max	4.5%
Voltage - Output (Max)	11V
Input Voltage Absolute-Max	70V
Adjustability	FIXED/ADJUSTABLE
Load Regulation-Max(%)	0.04%
Length	5mm
Height Seated (Max)	0.8mm
Width	5mm
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free

MAX5087AATE+ Product Details

MAX5087AATE+ Overview

In the case of Tube cases, the regulater IC is delivered. Packaging of the Liner regulator IC takes the form of a 16-WQFN Exposed Pad case. The PMIC chip has 16 terminations. Adjustable (Fixed) is the Voltage Regulator Chip's output type. Linear IC consists of 1 battery regulators. The range of operating temperatures of Surface Mount are programmable in the Voltage Regulator Chip, so that the temperature can be varied as desired. Keeping the temperature at -40°C~125°C degrees is necessary for this regulator to function. There is an output function of Positive configured for this regulator. Currently, 400mA are being output by it at the moment. The sum of the pins in this unit is 16. The part includes 1 outputs in order to ensure that the voltage regulator IC performs effectively and in a timely manner. Here's the basic part number for this IC regulator: MAX5087.
