Name: LT3502IDC
Brand: Linear Technology/Analog Devices
SKU: LT3502IDC
Availability: InStock

Technical Specifications

Parameter Name	Value
Type	Parameter
Mounting Type	Surface Mount
Package / Case	8-WFDFN Exposed Pad
Surface Mount	YES
Operating Temperature	-40°C~125°C TJ
Packaging	Tube
JESD-609 Code	e0
Pbfree Code	no
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	10
ECCN Code	EAR99
Terminal Finish	Tin/Lead (Sn/Pb)
Subcategory	Switching Regulator or Controllers
Terminal Position	DUAL
Peak Reflow Temperature (Cel)	235
Terminal Pitch	0.45mm
[email protected] Reflow Temperature-Max (s)	20
Base Part Number	LT3502
Function	Step-Down
Number of Outputs	1
Voltage - Input (Max)	40V
Output Type	Adjustable
Voltage - Input (Min)	3V
Input Voltage-Nom	10V
Analog IC - Other Type	SWITCHING REGULATOR
Output Configuration	Positive
Current - Output	500mA
Voltage - Output (Min/Fixed)	0.8V
Topology	Buck
Control Mode	CURRENT-MODE
Frequency - Switching	1.1MHz
Control Technique	PULSE WIDTH MODULATION
Synchronous Rectifier	No
Voltage - Output (Max)	36V
Height Seated (Max)	0.8mm
Length	2mm
Width	2mm
RoHS Status	Non-RoHS Compliant

LT3502IDC Product Details

LT3502IDC Overview

As a result of the use of the Tube package, the performance of this voltage regulator is optimized. In this voltage regulator, there are a total of 10 terminations. As a matter of fact, the type of analog IC that this voltage regulator 12v is equipped with is called SWITCHING REGULATOR. Space savings are achieved by placing this voltage regulator in the 8-WFDFN Exposed Pad package. DC DC switching regulator is configured with 1 outputs. On its output pins, this adjusting voltage regulator generates Adjustable output. Switching regulators like this one can be mounted on the Surface Mount mounting system. Keeping dc to dc voltage regulator's operating temperature at -40°C~125°C TJ is essential when operating. There is a switching frequency of 1.1MHz for this voltage regulator 12v. This voltage regulator is able to operate with the minimal input voltage of 3V. According to the table below, DC DC switching regulator's output voltage (Min/Fixed) is equal to 0.8V. It features maximum design flexibility due to dc to dc voltage regulator's 500mA output current. There is a maximum input voltage of 40V for this voltage regulator 12v. As a result of its peak reflow temperature, this voltage regulator is virtually indestructible. To meet the operation requirements, voltage regulator is designed to provide 10V as the nominal input voltage. Listed under the subcategory of Switching Regulator or Controllers is this voltage regulator 12v. This DC/DC regulator belongs to the LT3502 family. By using the 36V's maximal output voltage, adjusting voltage regulator can operate easily.
