Name: FH29-70S-0.2SHW(05)
Brand: Hirose Electric Co Ltd
SKU: FH29-70S-0.2SHW(05)
Availability: InStock

new-10%

FH29-70S-0.2SHW(05)

Manufacturer part number:FH29-70S-0.2SHW(05)

Manufacturer:Hirose Electric Co Ltd

Description:FH29-70S-0.2SHW(05) datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Hirose Electric Co Ltd stock available on our website

Case Package:SOT-23

Datasheet:FH29-70S-0.2SHW(05) Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Phosphor Bronze
Contact Plating	Gold
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Liquid Crystal Polymer (LCP)
Actuator Material	Polyamide (PA), Nylon
Operating Temperature	-55°C~85°C
Packaging	Tape & Reel (TR)
Series	FH29
Feature	Zero Insertion Force (ZIF)
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	70
Max Operating Temperature	85°C
Min Operating Temperature	-55°C
Voltage - Rated	40V
Current Rating (Amps)	0.25A
Pitch	0.008 0.20mm
Current Rating	250mA
Contact Finish	Gold
Lead Pitch	200μm
Number of Contacts	70
Housing Color	Beige
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Bottom
Cable End Type	Tabbed
Locking Feature	Flip Lock
Actuator Color	Brown
Contact Finish Thickness	Flash
Height Above Board	0.047 1.20mm
FFC, FCB Thickness	0.20mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

FH29-70S-0.2SHW(05) Product Details

FH29-70S-0.2SHW(05) Overview

This device is mounted in the Surface Mount, Right Angle position.The product is packaged in a Tape & Reel (TR) case.Specifically, it is one of the products in the FH29 Series.The ideal temperature for using it is below 85°C.Temperature must be -55°C to operate this device.As a result of its Zero Insertion Force (ZIF) feature, it possesses a great deal of power.Surface Mount is mounting the part.The device is operating at -55°C~85°C Operating Temperature.
