Name: M80-7900745
Brand: Harwin Inc.
SKU: M80-7900745
Availability: InStock

new-10%

M80-7900745

Manufacturer part number:M80-7900745

Manufacturer:Harwin Inc.

Description:1 RowsReceptacleSolderBeryllium CopperThrough HoleTubeGoldPolyamide (PA46), Nylon 4/6, Glass Filled7 PositionsFemale Socket

Case Package:SOT-23

Datasheet:M80-7900745 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Contact Material	Beryllium Copper
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	SIL
Contact Shape	Circular
Insulation Material	Polyamide (PA46), Nylon 4/6, Glass Filled
Operating Temperature	-55°C~125°C
Packaging	Tube
Published	2009
Series	Datamate L-Tek
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Receptacle
Number of Positions	7
Applications	Automotive, General Purpose, Military
Number of Rows	1
Voltage - Rated	120V
Additional Feature	POLARISED
Fastening Type	Locking Ramp
Subcategory	Headers and Edge Type Connectors
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Female Socket
Mixed Contacts	NO
Terminal Pitch	2mm
Insulation Height	0.202 5.14mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.079 2.00mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Contact Length - Post	0.177 4.50mm
Number Of PCB Rows	1
PCB Contact Pattern	RECTANGULAR
Mating Information	MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code	94V-0
Body Depth	0.202 inch
Contact Resistance	25mOhm
Durability	500 Cycles
Contact Finish Thickness - Mating	12.0μin 0.30μm
Contact Finish Thickness - Post	10.0μin 0.25μm
Stack Height (Mating)	7.23mm 7.83mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

M80-7900745 Product Details

M80-7900745 Overview

It comes in a Receptacle package.It's mounted Through Hole.It has been determined that a Tube case is necessary to package the product.As a product of the Datamate L-Tek Series, it can be found in this category.Among other features are POLARISED, to name only a few.The packaging with the SIL contains a device.A possible application for the device is Automotive, General Purpose, Military.There's a Through Hole mount on the part.The device runs in -55°C~125°C Operating Temperature.
