Name: M50-3600542R
Brand: Harwin Inc.
SKU: M50-3600542R
Price: 1.53000 USD
Availability: InStock

new-10%

M50-3600542R

Manufacturer part number:M50-3600542R

Manufacturer:Harwin Inc.

Description:Conn Unshrouded Header HDR 10 POS 1.27mm Solder ST SMD

Case Package:SOT-23

Datasheet:M50-3600542R Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	13 Weeks
Contact Material	Copper Alloy
Mounting Type	Surface Mount
Contact Shape	Square
Insulation Material	Thermoplastic
Mounting Option 1	LOCKING
Operating Temperature	-40°C~105°C
Packaging	Tape & Reel (TR)
Published	2012
Series	Archer M50
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	Header
Number of Positions	10
Number of Rows	2
Gender	Male
Additional Feature	LOW PROFILE
HTS Code	8536.69.40.40
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Contact Type	Male Pin
Mixed Contacts	NO
Option	GENERAL PURPOSE
Total Number of Contacts	10
Orientation	Straight
Depth	3.41mm
Insulation Height	0.039 1.00mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.050 1.27mm
Insulation Color	Black
Number of Conductors	ONE
Reference Standard	UL
Reliability	COMMERCIAL
Row Spacing - Mating	0.050 (1.27mm)
Shrouding	Unshrouded
Number Of PCB Rows	2
Contact Finish - Post	Tin
Contact Length - Mating	0.118 3.00mm
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.134 inch
UL Flammability Code	94V-0
Rated Current (Signal)	1A
Contact Resistance	30mOhm
Mating Contact Pitch	0.05 inch
Max Current Rating	1A
PCB Contact Row Spacing	3.9116 mm
Durability	300 Cycles
Length	6.35mm
Contact Finish Thickness - Mating	3.00μin 0.076μm
Contact Finish Thickness - Post	98.4μin 2.50μm
Stack Height (Mating)	3.9mm 5.3mm 6.08mm 6.18mm 7mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
