Name: ECS-3225MVQ-240-CN-TR
Brand: ECS Inc International
SKU: ECS-3225MVQ-240-CN-TR
Price: 1.29000 USD
Availability: InStock

new-10%

ECS-3225MVQ-240-CN-TR

Manufacturer part number:ECS-3225MVQ-240-CN-TR

Manufacturer:ECS Inc International

Description:ECS-3225MVQ-240-CN-TR datasheet pdf and Oscillators product details from ECS Inc International stock available on our website

Case Package:SOT-23

Datasheet:ECS-3225MVQ-240-CN-TR Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Package / Case	MINI-CSMD
ECCN (US)	EAR99
HTS	8542.39.00.01
Standard Frequency (MHz)	24
Frequency Stability (ppm)	±25
Load Capacitance (pF)	15
Maximum Symmetry (%)	55
Minimum Operating Supply Voltage (V)	1.7
Maximum Operating Supply Voltage (V)	3.6
Typical Operating Supply Voltage (V)	3.3\|2.5\|1.8
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Supplier Temperature Grade	Extended
Supplier Package	Mini-CSMD
Mounting	Surface Mount
Package Height	1
Package Length	3.2
Package Width	2.5
PCB changed	4
Product Depth (mm)	2.5(mm)
Operating Temp Range	-40C to 85C
Operating Supply Voltage (Max)	3.6(V)
Operating Supply Voltage (Typ)	1.8/2.5/3.3
Rad Hardened	No
Operating Supply Voltage (Min)	1.7(V)
Symmetry Max	55(%)
Programmable	No
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Packaging	Tape and Reel
Series	3225MVQ
Type	Crystal Oscillator
Frequency	24(MHz)
Frequency Stability	±25(ppm)
Pin Count	4
Termination Style	SMD/SMT
Load Capacitance	15(pF)
Product Type	Standard Oscillators
Screening Level	Industrial
Output Format	CMOS
Output Level	HCMOS
Product Length (mm)	3.2(mm)
Width	2.5 mm
Height	1 mm
Length	3.2 mm
Product Height (mm)	1(mm)
RoHS Status	RoHS Compliant

About ECS-3225MVQ-240-CN-TR

The ECS-3225MVQ-240-CN-TR from ECS Inc International is a high-performance microcontroller designed for a wide range of embedded applications. This component features ECS-3225MVQ-240-CN-TR datasheet pdf and Oscillators product details from ECS Inc International stock available on our website.

Key Features

Advanced AVR architecture for efficient processing
Wide operating temperature range: -40°C to 85°C
Low power consumption for energy-efficient applications
Comprehensive peripheral set including SPI, UART, and USART interfaces

Applications

This microcontroller is ideal for various applications including:

Industrial control systems
Consumer electronics
Automotive systems
IoT devices
Medical equipment

Technical Support

Hotenda provides comprehensive technical support for the ECS-3225MVQ-240-CN-TR, including datasheets, application notes, and design resources. Our team of engineers is available to assist with your design challenges.
