Name: ZXMC3AMCTA
Brand: Diodes Incorporated
SKU: ZXMC3AMCTA
Price: 1.09000 USD
Availability: InStock

new-10%

ZXMC3AMCTA

Manufacturer part number:ZXMC3AMCTA

Manufacturer:Diodes Incorporated

Description:Trans MOSFET N/P-CH 30V 3.7A/2.7A Automotive 8-Pin DFN EP T/R

Case Package:SOT-23

Datasheet:ZXMC3AMCTA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	17 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount
Package / Case	8-WDFN Exposed Pad
Number of Pins	8
Transistor Element Material	SILICON
Operating Temperature	-55°C~150°C TJ
Packaging	Tape & Reel (TR)
Published	2010
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	8
ECCN Code	EAR99
Resistance	210mOhm
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature	HIGH RELIABILITY
Subcategory	Other Transistors
Max Power Dissipation	1.7W
Terminal Position	DUAL
Peak Reflow Temperature (Cel)	260
[email protected] Reflow Temperature-Max (s)	40
Pin Count	8
Number of Elements	2
Operating Mode	ENHANCEMENT MODE
Power Dissipation	2.45W
Case Connection	DRAIN
Turn On Delay Time	1.5 ns
FET Type	N and P-Channel
Transistor Application	SWITCHING
Rds On (Max) @ Id, Vgs	120m Ω @ 2.5A, 10V
Vgs(th) (Max) @ Id	3V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds	190pF @ 25V
Current - Continuous Drain (Id) @ 25°C	2.9A 2.1A
Gate Charge (Qg) (Max) @ Vgs	3.9nC @ 10V
Rise Time	2.8ns
Drain to Source Voltage (Vdss)	30V
Polarity/Channel Type	N-CHANNEL AND P-CHANNEL
Fall Time (Typ)	7.5 ns
Turn-Off Delay Time	11.3 ns
Continuous Drain Current (ID)	2.1A
Gate to Source Voltage (Vgs)	20V
Drain Current-Max (Abs) (ID)	3.7A
Drain to Source Breakdown Voltage	-30V
Pulsed Drain Current-Max (IDM)	13A
FET Technology	METAL-OXIDE SEMICONDUCTOR
FET Feature	Logic Level Gate
Height	780μm
Length	3.08mm
Width	2.075mm
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
