Name: CY9BF505NBBGL-GK6E1
Brand: Cypress Semiconductor Corp
SKU: CY9BF505NBBGL-GK6E1
Availability: InStock

new-10%

CY9BF505NBBGL-GK6E1

Manufacturer part number:CY9BF505NBBGL-GK6E1

Manufacturer:Cypress Semiconductor Corp

Description:384KB 384K x 8 FLASH ARM® Cortex®-M3 32-Bit Microcontroller FM3 MB9B500B Series 4.5V 112-LFBGA

Case Package:SOT-23

Datasheet:CY9BF505NBBGL-GK6E1 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	20 Weeks
Mounting Type	Surface Mount
Package / Case	112-LFBGA
Surface Mount	YES
Operating Temperature	-40°C~85°C TA
Packaging	Tray
Series	FM3 MB9B500B
Part Status	Active
Moisture Sensitivity Level (MSL)	3 (168 Hours)
Number of Terminations	112
Terminal Position	BOTTOM
Terminal Form	BALL
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Supply Voltage	4.5V
Terminal Pitch	0.8mm
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
JESD-30 Code	S-PBGA-B112
Supply Voltage-Max (Vsup)	5.5V
Supply Voltage-Min (Vsup)	2.7V
Oscillator Type	Internal
Number of I/O	80
Speed	80MHz
RAM Size	48K x 8
Voltage - Supply (Vcc/Vdd)	2.7V~5.5V
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
Core Processor	ARM® Cortex®-M3
Peripherals	DMA, LVD, POR, PWM, WDT
Clock Frequency	48MHz
Program Memory Type	FLASH
Core Size	32-Bit
Program Memory Size	384KB 384K x 8
Connectivity	CANbus, CSIO, EBI/EMI, I2C, LINbus, UART/USART, USB
Bit Size	32
Data Converter	A/D 16x12b
Has ADC	YES
DMA Channels	YES
PWM Channels	YES
Address Bus Width	25
ROM (words)	393216
On Chip Program ROM Width	8
External Data Bus Width	16
RAM (bytes)	49152
Length	10mm
Height Seated (Max)	1.45mm
Width	10mm
RoHS Status	ROHS3 Compliant

CY9BF505NBBGL-GK6E1 Product Details

CY9BF505NBBGL-GK6E1 Overview
