Name: DMT6D1K
Brand: Cornell Dubilier Electronics (CDE)
SKU: DMT6D1K
Availability: InStock

new-10%

DMT6D1K

Manufacturer part number:DMT6D1K

Manufacturer:Cornell Dubilier Electronics (CDE)

Description:DMT 1000pF Film Capacitor ±10% Radial PC Pins 630V-DC 250V-AC Polyester, Metallized Through Hole

Case Package:SOT-23

Datasheet:DMT6D1K Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mount	Through Hole
Mounting Type	Through Hole
Package / Case	Radial
Terminal Shape	WIRE
Dielectric Material	Polyester, Metallized
Operating Temperature	-55°C~125°C
Packaging	Bulk
Published	2013
Series	DMT
Size / Dimension	0.693Lx0.217W 17.60mmx5.50mm
Tolerance	±10%
JESD-609 Code	e3
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	PC Pins
ECCN Code	EAR99
Terminal Finish	Tin (Sn)
Applications	General Purpose
Additional Feature	RATED AC VOLTAGE (V): 250
HTS Code	8532.25.00.70
Capacitance	1000pF
Voltage - Rated DC	630V
Terminal Pitch	13.8mm
Reach Compliance Code	unknown
Voltage - Rated AC	250V
Lead Pitch	13.7922mm
Capacitor Type	FILM CAPACITOR
Lead Spacing	0.543 13.80mm
Rated (DC) Voltage (URdc)	600V
Size Code	6922
Custom Capabilities	Other Capacitance Values,Sizes Available
Height Seated (Max)	0.421 10.70mm
Length	17.6mm
Width	5.5mm
RoHS Status	Non-RoHS Compliant

DMT6D1K Product Details

DMT6D1K Overview

For systems to operate, a rated (DC) voltage (URdc) of 600V must be applied internally.Lead spacing is 0.543 13.80mm for this electrical device.Devices with a -55°C~125°C temperature capability can be operated.
