EP2AGX125EF29C4N Overview
There are two packages that contain fpga chips: 780-BBGA, FCBGA package and X package. An FPGA of this type is made up of FIELD PROGRAMMABLE GATE ARRAY gates. Fpga chips is programmed wFpga chipsh 372 I/Os for transferring data in a more coherent manner. A fundamental building block consists of 118143 logic elements/cells. 0.9V volts power it. The Field Programmable Gate Arrays family of FPGA parts includes this part. The Surface Mount-slot connector on the FPGA module can be connected to the development board. In order to operate it, it requires a voltage supply of 0.87V~0.93V . It is a type of FPGA belonging to the Arria II GX seies. As far as the operating temperature is concerned, it should be kept within 0°C~85°C TJ when operating. In this device, there are 372 outputs that can be used. Using the Tray layout, this FPGA model can be contained in a very small amount of space. In total, it has 780 terminations on each end. Having a RAM bit size of 8315904 means that this device will offer you a lot of memory. If you are looking for related parts, you can use the base part number EP2AGX125 as a starting point. The FPGA consists of 4964 LABs/CLBs. Fpga electronics operates from a 0.91.2/3.31.52.5V power supply. It usually uses a crystal oscillating at a frequency of 500MHz in order to do its work. For its architecture, 124100 CLB modules are used.
EP2AGX125EF29C4N Features
372 I/Os
Up to 8315904 RAM bits
EP2AGX125EF29C4N Applications
There are a lot of Intel EP2AGX125EF29C4N FPGAs applications.
- Data center search engines
- Industrial Ethernet
- Wireless Communications
- Cryptography
- Automotive
- Bioinformatics
- Medical Electronics
- Electronic Warfare
- Digital signal processing
- Enterprise networking
