90156-0165

90156-0165

90156-0165

Molex

1 Rows Receptacle, Socket Bulk Black PPO

SOT-23

90156-0165 Datasheet PDF

non-compliant

Technical Specifications

Parameter NameValue
TypeParameter
Factory Lead Time 12 Weeks
Mount Cable, Free Hanging
Housing Material PPO
PackagingBulk
Published 2008
Pbfree Code yes
Part StatusActive
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Socket
Max Operating Temperature105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
HTS Code8536.69.40.40
Fastening TypeRamp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Depth 15.24mm
Current Rating3A
Reference Standard UL
Reliability COMMERCIAL
Number of Contacts 25
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Body/Shell Style PLUG
Durability 500 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 2.9468 N
Glow Wire Compliant Non-compliant
Length 64.56mm
Width 5.35mm
Radiation HardeningNo
RoHS StatusRoHS Compliant
Lead Free Lead Free
In-Stock:7004 items

Pricing & Ordering

QuantityUnit PriceExt. Price

90156-0165 Product Details

90156-0165 Overview


The packaging is Receptacle, Socket.To package the product, we use a Bulk case.Mounted by Cable, Free Hanging.

90156-0165 Features




90156-0165 Applications


There are a lot of Molex
90156-0165 Rectangular Connectors applications.


  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
  • Electrical substations
