5AGXMA5D4F27I3N Overview
Fpga chips is supplied in the 672-BBGA, FCBGA package. FIELD PROGRAMMABLE GATE ARRAY is the component of this type of FPGA. The I/Os are designed to facilitate a more coherent transfer of data. The basic building blocks of logic contain 190000 logic elements/cells. Supply voltage is 1.15V volts. Surface Mount-connectors can be used to attach this FPGA module to the development board. Fpga chips operates at a voltage of 1.12V~1.18V and uses a battery to supply power. It is a type of FPGA that belongs to the Arria V GX series of FPGAs. The operating temperature should be kept at -40°C~100°C TJ when operating. A model of this FPGA is contained in Tray for the purpose of saving space. As a whole, it has 672 terminations. This device is equipped with 13284352 RAM bits in terms of its RAM si13284352e. In order to find related parts, use the part number 5AGXMA5 as a base. 8962 LABs and CLBs are built into this FPGA. It usually uses a crystal oscillating at a frequency of 670MHz in order to do its work.
5AGXMA5D4F27I3N Features
336 I/Os
Up to 13284352 RAM bits
5AGXMA5D4F27I3N Applications
There are a lot of Intel 5AGXMA5D4F27I3N FPGAs applications.
- Data Center
- Voice recognition
- Video & Image Processing
- Electronic Warfare
- Military DSP
- Enterprise networking
- Solar Energy
- Wired Communications
- Aircraft navigation
- ADAS
