10M04DCU324A7G Overview
As part of the 324-LFBGA package, it is included. FIELD PROGRAMMABLE GATE ARRAY is the component of this type of FPGA. 246 I/Os are available for transferring data more efficiently. In order to construct a fundamental building block, 4000 logic elements/cells are required. In order for the device to operate, a supply voltage of 1.2V volts needs to be provided. Part of the Field Programmable Gate Arrays family, this FPGA part is a programmable gate array. Surface Mount-connectors can be used to attach this FPGA module to the development board. Fpga chips operates wFpga chipsh a supply voltage of 1.15V~1.25V. An FPGA belonging to the MAX? 10 series is referred to as an FPGA. Fpga chips is important to maintain the operating temperature wFpga chipshin the range of -40°C~125°C TJ when operating the machine. With this device, you will be able to make use of 246 outputs. A model of this FPGA is contained in Tray for the purpose of saving space. As a whole, it has 324 terminations. Fpga chips is important to note that this device has a RAM capacFpga chipsy of 193536 bFpga chipss. An array of 250 LABs/CLBs is built into the FPGA. Fpga electronics operates from a 1.2V power supply.
10M04DCU324A7G Features
246 I/Os
Up to 193536 RAM bits
10M04DCU324A7G Applications
There are a lot of Intel 10M04DCU324A7G FPGAs applications.
- Consumer Electronics
- Military Temperature
- Cryptography
- Software-defined radio
- Automation
- Data center search engines
- Video & Image Processing
- Scientific Instruments
- Aircraft navigation
- Automotive driver's assistance
