10AX032E1F27E1SG Overview
There are two packages that contain fpga chips: 672-BBGA, FCBGA package and X package. There are FIELD PROGRAMMABLE GATE ARRAY transistors in this type of FPGA. 240 I/Os are available for transferring data more efficiently. Logic blocks consist of 320000 logic elements/cells. It is powered from a supply voltage of 0.9V. There is a Field Programmable Gate Arrays family component in this FPGA part. This FPGA module can be attached to the development board with a Surface Mount. Powered by a 0.87V~0.98V supply voltage, fpga chips is able to operate at high speeds. It is a type of FPGA belonging to the Arria 10 GX seies. During the operation of the system, the operating temperature should remain within the range of 0°C~100°C TJ. A total of 240 outputs are incorporated into this device. As a space-saving measure, this FPGA model is contained within Tray. As a whole, it has 672 terminations. A device like this one offers 21040128 RAM bits, which is a considerable amount of memory. 119900 LABs/CLBs are integrated into this FPGA. Fpga electronics operates from a 0.9V power supply.
10AX032E1F27E1SG Features
240 I/Os
Up to 21040128 RAM bits
10AX032E1F27E1SG Applications
There are a lot of Intel 10AX032E1F27E1SG FPGAs applications.
- Secure Communication
- Aerospace and Defense
- DO-254
- Telecommunication
- Development Boards and Shields for Microcontrollers
- Distributed Monetary Systems
- Device controllers
- Scientific Instruments
- Security systems
- Ecosystem
