Name: 0520450845
Brand: Molex
SKU: 0520450845
Availability: InStock

new-10%

0520450845

Manufacturer part number:0520450845

Manufacturer:Molex

Description:0520450845 datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0520450845 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	10 Weeks
Contact Material	Phosphor Bronze
Mounting Type	Through Hole
Housing Material	Polybutylene Terephthalate (PBT), Polyester
Operating Temperature	-40°C~85°C
Packaging	Tray
Series	52045
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Kinked Pin
ECCN Code	EAR99
Connector Type	FFC/FPC CONNECTOR
Number of Positions	8
Number of Rows	1
Gender	Female
Voltage - Rated	200V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.049 1.25mm
Total Number of Contacts	8
Orientation	Vertical
Depth	5.1mm
Current Rating	1A
Contact Finish	Tin
Housing Color	Gray
Contact Resistance	30mOhm
Body/Shell Style	RECEPTACLE
Number of Circuits	7
Halogen Free	Halogen Free
Flat Flex Type	FFC, FPC
Connector/Contact Type	Contacts, Vertical - 1 Sided
Cable End Type	Straight
Stackable	No
Length	13.4mm
Contact Finish Thickness	35.4μin 0.90μm
Height Above Board	0.315 8.00mm
FFC, FCB Thickness	0.30mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0520450845 Product Details

0520450845 Overview

Packaging is FFC/FPC CONNECTOR.Mounting type Through Hole is assigned to the device.Packaging the product involves using a Tray case.It belongs to the 52045 Series of products.A total of 7 circuits are present in the part.It operates at an operating temperature of -40°C~85°C.
