Name: XF3C234541ABYOMZ
Brand: Omron Electronics Inc-EMC Div
SKU: XF3C234541ABYOMZ
Availability: InStock

new-10%

XF3C234541ABYOMZ

Manufacturer part number:XF3C234541ABYOMZ

Manufacturer:Omron Electronics Inc-EMC Div

Description:XF3C234541ABYOMZ datasheet pdf and FFC, FPC (Flat Flexible) Connectors product details from Omron Electronics Inc-EMC Div stock available on our website

Case Package:SOT-23

Datasheet:XF3C234541ABYOMZ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Copper Alloy
Contact Plating	Gold
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Housing Material	Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material	Liquid Crystal Polymer (LCP), Halogen Free
Operating Temperature	-30°C~85°C
Packaging	Tape & Reel (TR)
Published	2017
Series	XF3C
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Number of Positions	23
Max Operating Temperature	85°C
Min Operating Temperature	-30°C
Number of Rows	1
Voltage - Rated	50V
Current Rating (Amps)	0.2A
Pitch	0.010 0.25mm
Orientation	Right Angle
Current Rating	200mA
Contact Finish	Gold
Number of Contacts	23
Housing Color	Natural
Wire/Cable Type	Straight
Mating Cycles	20
Flat Flex Type	FPC
Connector/Contact Type	Contacts, Top and Bottom
Cable End Type	Straight
Locking Feature	Rotary Lock, Backlock
Actuator Color	Black
Contact Finish Thickness	5.90μin 0.150μm
Height Above Board	0.033 0.84mm
FFC, FCB Thickness	0.12mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

XF3C234541ABYOMZ Product Details

XF3C234541ABYOMZ Overview

This device is mounted in the Surface Mount, Right Angle position.To package the product, we use a Tape & Reel (TR) case.This product is part of the XF3C Series.Whenever the temperature is below 85°C, it's best.There is a minimum temperature requirement of [0°C] for this device.By Surface Mount, the part is mounted.It runs at -30°C~85°C Operating Temperature.
