Name: 0395026004
Brand: Molex
SKU: 0395026004
Price: 1.74000 USD
Availability: InStock

new-10%

0395026004

Manufacturer part number:0395026004

Manufacturer:Molex

Description:0395026004 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Molex stock available on our website

Case Package:SOT-23

Datasheet:0395026004 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Brass
Contact Plating	Tin
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Polyamide (PA66), Nylon 6/6
Operating Temperature	-40°C~105°C
Packaging	Bulk
Series	Eurostyle ESE 39502
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Type	Header, Male Pins, Shrouded (4 Side)
Number of Positions	4
Max Operating Temperature	105°C
Min Operating Temperature	-40°C
Color	Green
Number of Rows	1
Pitch	0.138 3.50mm
Orientation	Right Angle
Depth	9.2mm
Insulation Height	0.270 6.86mm
Termination Style	Solder
Number of Contacts	4
Housing Color	Green
Contact Resistance	8mOhm
Voltage	300V
Contact Tail Length	0.140 3.56mm
Number of Levels	1
Current	8A
Contact Mating Finish	Tin
Voltage - UL	300V
Current - UL	8A
Positions Per Level	4
Header Orientation	90°, Right Angle
Number of Positions Per Level	4
Length	15.39mm
Material Flammability Rating	UL94 V-0
RoHS Status	ROHS3 Compliant

0395026004 Product Details

0395026004 Overview

Mounting type Through Hole is assigned to the device.It is necessary to use a Bulk case for packaging the product.It's from the Eurostyle ESE 39502 Series.If it is to be used, it should be kept at a temperature below 105°C.A minimum operating temperature of -40°C is required for this device.Through Hole is mounting the part.Devices operate at -40°C~105°C operating temperatures.There are many benefits shared between this part and other Header, Male Pins, Shrouded (4 Side) products.
