Name: 0009523043
Brand: Molex
SKU: 0009523043
Availability: InStock

new-10%

0009523043

Manufacturer part number:0009523043

Manufacturer:Molex

Description:1 Rows Receptacle Solder Brass Through Hole Tray Tin Polyamide (PA), Nylon 4 Positions Female Socket

Case Package:SOT-23

Datasheet:0009523043 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Contact Material	Brass
Mounting Type	Through Hole
Contact Shape	Square
Insulation Material	Polyamide (PA), Nylon
Operating Temperature	-40°C~80°C
Packaging	Tray
Series	KK 2145
Feature	Board Hooks
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
Connector Type	Receptacle
Number of Positions	4
Applications	Automotive, General Purpose, Medical, Telecommunications
Number of Rows	1
Voltage - Rated	600V
Fastening Type	Locking Ramp
Contact Finish - Mating	Tin
Contact Type	Female Socket
Current Rating (Amps)	4.5A
Insulation Height	0.449 11.40mm
Style	Board to Board or Cable
Number of Positions Loaded	All
Pitch - Mating	0.156 3.96mm
Insulation Color	White
Contact Length - Post	0.120 3.05mm
Contact Finish Thickness - Mating	100.0μin 2.54μm
Contact Finish Thickness - Post	100.0μin 2.54μm
Material Flammability Rating	UL94 V-2
RoHS Status	ROHS3 Compliant

0009523043 Product Details

0009523043 Overview

The packaging contains Receptacle.There is a Through Hole mounting type for the device.This product is packaged in a case marked Tray.Product number KK 2145 belongs to the KK 2145 Series.In addition to Automotive, General Purpose, Medical, Telecommunications, there are other possible applications for the device.In many ways, it is more powerful due to its Board Hooks feature.This device operates at a temperature of -40°C~80°C.
