SD04H0SBR datasheet pdf and DIP Switches product details from C&K stock available on our website
SOT-23
SD04H0SBR Datasheet PDF
non-compliant
Technical Specifications
Parameter Name
Value
Type
Parameter
Factory Lead Time
13 Weeks
Contact Material
Beryllium Copper
Mount
Surface Mount
Mounting Type
Surface Mount
Body Material
Polyphthalamide (PPA)
Actuator Material
Nylon
Operating Temperature
-40°C~85°C
Packaging
Tape & Reel (TR)
Published
2011
Series
SD
Feature
Tape Seal
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Termination
Gull Wing
Number of Positions
4
Voltage - Rated
25VDC
Voltage - Rated DC
25V
Pitch
0.100 2.54mm Full
Orientation
Straight
Terminal Pitch
2.54mm
Depth
9.91mm
Current Rating
100mA
Contact Finish
Gold
Termination Style
Gull Wing
Actuator Type
Slide (Standard)
Circuit
SPST
Max Current Rating
100mA
Electrical Life
2,000 Cycles
Max Voltage Rating (DC)
25V
Mechanical Life
2,000 Cycles
Washable
Yes
Actuator Level
Flush, Recessed
Life (Cycles)
2000 cycles
Length
0.458 11.63mm
Actuator Length
0m
Height Above Board
0.170 4.33mm
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free
In-Stock:2675 items
Pricing & Ordering
Quantity
Unit Price
Ext. Price
1
$2.693273
$2.693273
10
$2.540823
$25.40823
100
$2.397003
$239.7003
500
$2.261324
$1130.662
1000
$2.133324
$2133.324
SD04H0SBR Product Details
C&K Components DIP Switches SD04H0SBR are low profile, single-pole, single-throw (SPST) switches with four positions. They are designed to provide reliable switching performance in a variety of applications. The switches feature a low profile design, allowing them to fit into tight spaces. They are constructed with a durable plastic housing and gold-plated contacts for reliable operation.
Features of the C&K Components DIP Switches SD04H0SBR include:
The C&K Components DIP Switches SD04H0SBR are suitable for a variety of applications, including consumer electronics, automotive, industrial, and medical. They are ideal for use in applications where space is limited, such as in portable devices or in tight enclosures. They can also be used in applications where reliable switching performance is required, such as in control systems or in test and measurement equipment.
