Name: MS3472W22-55SZ
Brand: Amphenol Aerospace Operations
SKU: MS3472W22-55SZ
Price: 84.68000 USD
Availability: InStock

new

MS3472W22-55SZ

Manufacturer part number:MS3472W22-55SZ

Manufacturer:Amphenol Aerospace Operations

Description:Receptacle, Female Sockets Aluminum Panel Mount 55 (Power) Positions Crimp Gold Olive Drab Cadmium Bulk Z Bayonet Lock

Case Package:SOT-23

Datasheet:MS3472W22-55SZ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Material	Copper Alloy
Mount	Flanges, Panel, Wall
Mounting Type	Panel Mount
Mounting Feature	Flange
Shell Material	Aluminum
Operating Temperature	-65°C~200°C
Packaging	Bulk
Series	Military, MIL-DTL-26482 Series II
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Crimp
Connector Type	Receptacle, Female Sockets
Number of Positions	55 (Power)
Color	Olive Drab
Applications	Aviation, Industrial, Military
Additional Feature	STANDARD: MIL-C-26482, COMPATIBLE CONTACT: M39029/5-115
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	YES
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Orientation	Z
Shielding	Unshielded
Ingress Protection	Environment Resistant
Current Rating	7.5A
Shell Finish	Olive Drab Cadmium
Shell Size - Insert	22-55
Number of Contacts	55
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Empty Shell	NO
Backshell Type	SOLID
Environmental Characteristics	FLUID RESISTANT
Contact Finish Thickness - Mating	50.0μin 1.27μm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Ratings	Environment Resistant

MS3472W22-55SZ Product Details

MS3472W22-55SZ Overview

Receptacle, Female Sockets packaging is included.This device has a mounting type of Panel Mount.We package the product with a Bulk case.The product is part of the Military, MIL-DTL-26482 Series II Series.Additionally, there are features like STANDARD: MIL-C-26482, COMPATIBLE CONTACT: M39029/5-115, just to name a few.You've got Flanges, Panel, Wall mounted on the part.This device runs at -65°C~200°C operating temperature.
