Name: MS27505E21B35SA
Brand: Amphenol Aerospace Operations
SKU: MS27505E21B35SA
Price: 110.53000 USD
Availability: InStock

new

MS27505E21B35SA

Manufacturer part number:MS27505E21B35SA

Manufacturer:Amphenol Aerospace Operations

Description:Receptacle, Female Sockets Aluminum Panel Mount 79 Positions Crimp Gold Olive Drab Cadmium over Nickel Bulk A Bayonet Lock

Case Package:SOT-23

Datasheet:MS27505E21B35SA Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	16 Weeks
Contact Material	Copper Alloy
Mount	Box, Flanges, Panel
Mounting Type	Panel Mount
Mounting Feature	Flange
Shell Material	Aluminum
Operating Temperature	-65°C~175°C
Packaging	Bulk
Series	Military, MIL-DTL-38999 Series I, LJT
Published	2006
JESD-609 Code	e4
Feature	Shielded
Pbfree Code	no
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Crimp
Connector Type	Receptacle, Female Sockets
Number of Positions	79
Color	Olive Drab
Applications	Aviation, Military
Fastening Type	Bayonet Lock
Contact Finish - Mating	Gold
MIL Conformance	YES
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Total Number of Contacts	79
Orientation	A
Shielding	Unshielded
Ingress Protection	Environment Resistant
Depth	39.67mm
Current Rating	5A
Military Standard	MIL-DTL-38999
Shell Finish	Olive Drab Cadmium over Nickel
Shell Size - Insert	21-35
Contact Gender	Female
Empty Shell	NO
Backshell Type	SOLID
Contact Style	Socket
Plating	Cadmium
Length	26mm
Contact Finish Thickness - Mating	50.0μin 1.27μm
Radiation Hardening	No
RoHS Status	Non-RoHS Compliant
Ratings	Environment Resistant

MS27505E21B35SA Product Details

MS27505E21B35SA Overview

Packaging for this item is Receptacle, Female Sockets.There is a mounting type of Panel Mount for this device.It is necessary to use a Bulk case for packaging the product.This product is part of the Military, MIL-DTL-38999 Series I, LJT Series.In many ways, its Shielded feature makes it more powerful.Box, Flanges, Panel is used to mount the part.In this case, the device operates at -65°C~175°C Operating Temperature.
