Name: AM10CW-2409S-NZ
Brand: Aimtec
SKU: AM10CW-2409S-NZ
Price: 23.05000 USD
Availability: InStock

new

AM10CW-2409S-NZ

Manufacturer part number:AM10CW-2409S-NZ

Manufacturer:Aimtec

Description:9V DC DC Voltage Regulator 1 Outputs -

Case Package:SOT-23

Datasheet:AM10CW-2409S-NZ Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Mounting Type	Through Hole
Package / Case	-
Supplier Device Package	-
Product Weight (g)	15
Minimum Input Voltage (V)	9
Typical Input Voltage (V)	24
Maximum Input Voltage (V)	36
Output Voltage (V)	9
Output Current (A)	1.11
Output Power (W)	10
Minimum Isolation Voltage	1500VDC(Typ)
Input/Output Type	DC/DC
Switching Frequency (kHz)	350(Typ)
Switching Regulator	Yes
Efficiency (%)	86
On/Off Logic	Positive
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Mounting	Through Hole
Package Height	11.7
Package Length	25.4
Package Width	25.4
PCB changed	5
Package	Tube
Base Product Number	AM10C
Mfr	aimtec
Product Status	Active
Operating Temperature	-40°C ~ 85°C
Series	AM10CW-NZ (10W)
Size / Dimension	1.00 L x 1.00 W x 0.46 H (25.4mm x 25.4mm x 11.7mm)
Part Status	Active
Type	Step Down
Applications	ITE (Commercial)
Power (Watts)	10 W
Pin Count	5
Number of Outputs	1
Approval Agency	CE, cURus, UL
Efficiency	86%
Voltage - Isolation	1.5 kV
Voltage - Input (Max)	36V
Output Type	Fixed
Voltage - Output 1	9V
Voltage - Input (Min)	9V
Current - Output (Max)	1.11A
Control Features	-
Voltage - Output 2	-
Voltage - Output 3	-
Voltage - Output 4	-
Isolation	Isolated
Line Regulation	0.5%
Load Regulation	1%
Features	Remote On/Off
RoHS Status	RoHS Compliant

AM10CW-2409S-NZ Product Details

AM10CW-2409S-NZ Overview

In order to save space, this harley voltage regulator is available in the - package. There are 1 outputs configured on this voltage regulator 12v. There are output pins on this DC DC switching regulator that generate Fixed output. Through Hole-mounting is compatible with this switching regulator. The operating temperature should be kept at -40°C ~ 85°C when the voltage regulator 12v is in operation. The voltage regulator can operate with a dc to dc voltage regulator's minimum input voltage of 9V. Voltage regulator has a maximum input voltage of 36V. As a member of the AM10CW-NZ (10W) family of DC/DC regulators, this part is prominent in many specifications. There are 5 pins on this DC-DC switching regulator.
