RC0603FR-072M74L

new-10%

Manufacturer part number:RC0603FR-072M74L

Manufacturer:Yageo

Description:Thick Film Resistors 2.74M OHM 1%

Case Package:SOT-23

Datasheet:RC0603FR-072M74L Datasheet

RoHs Status:non-compliant

Name	Value
Type	Parameter
Factory Lead Time	33 Weeks
Contact Plating	Tin
Package / Case	0603 (1608 Metric)
Surface Mount	YES
Terminal Shape	WRAPAROUND
Mounting Feature	SURFACE MOUNT
Weight	2.012816mg
Operating Temperature	-55°C~155°C
Packaging	Tape & Reel (TR)
Published	2010
Series	RC
Size / Dimension	0.063Lx0.031W 1.60mmx0.80mm
Tolerance	±1%
JESD-609 Code	e3
Feature	Moisture Resistant
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	SMD/SMT
ECCN Code	EAR99
Temperature Coefficient	±100ppm/°C
Resistance	2.74MOhm
Composition	Thick Film
Power (Watts)	0.1W 1/10W
Voltage - Rated	75V
Additional Feature	LASER TRIMMABLE
Power Rating	100mW
Packing Method	TR, PAPER, 7 INCH
Max Power Dissipation	100mW
Construction	Rectangular
Resistor Type	FIXED RESISTOR
Case Code (Metric)	1608
Rated Power Dissipation (P)	0.1W
Case Code (Imperial)	0603
Height	500μm
Height Seated (Max)	0.022 0.55mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant
