Name: CC1206KKX7RCBB682
Brand: Yageo
SKU: CC1206KKX7RCBB682
Price: 0.25000 USD
Availability: InStock

new-10%

CC1206KKX7RCBB682

Manufacturer part number:CC1206KKX7RCBB682

Manufacturer:Yageo

Description:CC1206KKX7RCBB682 datasheet pdf and Ceramic Capacitors product details from Yageo stock available on our website

Case Package:SOT-23

Datasheet:CC1206KKX7RCBB682 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	33 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount, MLCC
Package / Case	1206 (3216 Metric)
Terminal Shape	WRAPAROUND
Weight	16.187578mg
Operating Temperature	-55°C~125°C
Packaging	Tape & Reel (TR)
Published	2005
Series	CC
Size / Dimension	0.126Lx0.063W 3.20mmx1.60mm
Tolerance	±10%
JESD-609 Code	e3
Feature	High Voltage
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
Termination	SMD/SMT
Temperature Coefficient	X7R
Terminal Finish	Matte Tin (Sn) - with Nickel (Ni) barrier
Composition	Ceramic
Applications	General Purpose
Capacitance	6800pF
Voltage - Rated DC	1kV
Packing Method	TR, BLISTER, 7 INCH
Depth	1.6mm
Case Code (Metric)	3216
Case Code (Imperial)	1206
Temperature Characteristics Code	X7R
Multilayer	Yes
Rated (DC) Voltage (URdc)	1000V
Height	1.25mm
Length	3.2mm
Thickness (Max)	0.057 1.45mm
Thickness	1.4478mm
Radiation Hardening	No
RoHS Status	ROHS3 Compliant

CC1206KKX7RCBB682 Product Details

CC1206KKX7RCBB682 Overview

This device's program size/dimension is 0.126Lx0.063W 3.20mmx1.60mm.Its coefficient is X7R and determines the change in resistance per degree of temperature for a substance.Powered by voltage of 1kV, it can be operated with a voltage of rated DC.
