XC2VP2-5FF672C Overview
There is a 672-BBGA, FCBGA package that includes this component. This kind of FPGA is composed of FIELD PROGRAMMABLE GATE ARRAY. A total of 204 I/Os allow data to be transferred in a more coherent manner. There are 3168 logic elements/cells to form a fundamental building block. In order for the device to operate, a supply voltage of 1.5V volts needs to be provided. In this case, the FPGA part belongs to the Field Programmable Gate Arrays family. An FPGA module can be attached to a development board with a Surface Mount-pin. With a supply voltage of 1.425V~1.575V, this device operates with ease. As part of the Virtex?-II Pro series of FPGAs, it is a type of FPGA. The operating temperature should be kept at 0°C~85°C TJ when operating. There are 204 outputs incorporated in this device. Fpga chips is designed to maximiBulke space efficiency by containing the FPGA model in Bulk. Total terminations are 672. Fpga electronics is worth mentioning that this device provides 221184 bfpga electronics s of RAM. The RAM si27kBe of this FPGA module reaches 27kB so as to guarantee the normal operation of the program during operation. A total of 352 LABs/CLBs are included in this FPGA. Design engineers can fully take advantage of its flexibility when operating at 1.5V supply voltage. In addition to this, it has 672 pins. There are 2816 registers used to store and transfer data. The architecture of the system is based on 352 CLBs.
XC2VP2-5FF672C Features
204 I/Os
Up to 221184 RAM bits
2816 registers
XC2VP2-5FF672C Applications
There are a lot of Xilinx Inc. XC2VP2-5FF672C FPGAs applications.
- Radar and Sensors
- Filtering and communication encoding
- Aircraft navigation
- Electronic Warfare
- OpenCL
- Bioinformatics
- Data center hardware accelerators
- Military DSP
- Wired Communications
- Medical ultrasounds
