Name: 1940750000
Brand: Weidmüller
SKU: 1940750000
Price: 4.86000 USD
Availability: InStock

new-10%

1940750000

Manufacturer part number:1940750000

Manufacturer:Weidmüller

Description:1940750000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1940750000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Free Hanging
Mounting Type	Free Hanging (In-Line)
Insulation Material	Nylon
Housing Material	Polyamide (PA), Nylon, Glass Filled
Operating Temperature	-50°C~120°C
Packaging	Bulk
Published	2008
Series	Omnimate BC
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
ECCN Code	EAR99
Type	Plug, Female Sockets
Number of Positions	4
Color	Orange
Number of Rows	1
Voltage - Rated	300V
Pitch	0.150 3.81mm
Orientation	Right Angle
Ingress Protection	IP20
Depth	16.1mm
Insulation Height	0.437 11.10mm
Current Rating	17.5A
Termination Style	Screw - Clamping Yoke (Tension Sleeve)
Approval Agency	CSA, cURus
Voltage	300V
Max Supply Voltage	300V
Max Current Rating	10A
Number of Levels	1
Current	10A
Wire Gauge (Max)	28 AWG
Wire Gauge (Min)	16 AWG
Contact Mating Finish	Tin
Number of Decks	1
Wire Gauge or Range - AWG	16-28 AWG
Voltage - IEC	320V
Torque - Screw	0.2-0.25 Nm (1.7-2.2 Lb-In)
Number of Ways	4
Safety Approval	UL; CSA
Plug Wire Entry	180°
Wire Gauge or Range - mm²	0.2-1.5mm2
Current - IEC	17.5A
Number of Positions Per Level	4
Screw Size	M2
Stripping Length	7mm
Length	15.24mm
Material Flammability Rating	UL94 V-0
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0

1940750000 Product Details

1940750000 Overview

This device's mounting type is Free Hanging (In-Line).In order to package the product, a Bulk case is used.The product is part of the Omnimate BC Series.There's a Free Hanging mount on the part.It runs at -50°C~120°C Operating Temperature.This chip's supply voltage should not exceed 300V.There are many benefits that this part shares with other Plug, Female Sockets products as well.
