Name: 1796500000
Brand: Weidmüller
SKU: 1796500000
Price: 1.23000 USD
Availability: InStock

new-10%

1796500000

Manufacturer part number:1796500000

Manufacturer:Weidmüller

Description:1796500000 datasheet pdf and Terminal Blocks - Headers, Plugs and Sockets product details from Weidmüller stock available on our website

Case Package:SOT-23

Datasheet:1796500000 Datasheet PDF

RoHs Status:non-compliant

Parameter Name	Value
Type	Parameter
Factory Lead Time	12 Weeks
Contact Material	Copper Alloy
Mount	Through Hole
Mounting Type	Through Hole
Housing Material	Liquid Crystal Polymer (LCP), Glass Filled
Operating Temperature	-50°C~100°C
Packaging	Bulk
Published	2004
Series	Omnimate SL
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Type	Header, Male Pins, Shrouded (2 Side)
Color	Black
Number of Rows	1
Gender	Male
Voltage - Rated	300V
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Pitch	0.197 5.00mm
Total Number of Contacts	4
Insulation Height	0.472 12.00mm
Current Rating	15A
Termination Style	Solder
Voltage - Rated AC	300V
Approval Agency	CSA, UR
Lead Pitch	5mm
Insulation Resistance	1MOhm
Voltage	300V
Contact Tail Length	0.059 1.50mm
Number of Levels	1
Current	10A
Number of Poles	4
Contact Mating Finish	Tin
Current - UL	18.5A
Voltage - IEC	400V
Header Orientation	Vertical
Current - IEC	27.5A
Hole Diameter	1.4 mm
Height	12mm
Length	20mm
Width	8.5mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free

1796500000 Product Details

1796500000 Overview

It's mounted Through Hole.It is necessary to use a Bulk case for packaging the product.It's part of the Omnimate SL Series.In this case, Through Hole mounts the part.Operating temperature is -50°C~100°C.Other Header, Male Pins, Shrouded (2 Side) products share lots of benefits with this part.
